Rugged 2U Rack Mount Wide 17" Triple Screen Display 26" Deep (Model: DRP3DW17M)

DRP3DW17M
  • Overview
  • Specifications
  • Download

The DRP3DW17 Series is a high performance 2RU Triple LCD display drawer sporting 3 -17" LCD Monitors. These monitors have high contrast ratios (450:1) and wide viewing angles with a native WUXGA (1920x1200) resolution. They fold away to ft into a 2RU (3.5") space. Other options include Dual 19"and Dual 17" Wide Monitors.

The DRP3D Series is the ultimate compact mobile Side-by-Side Dual and Triple Monitor rack drawer solution utilizing only 2RU.
It employs i-Tech's patent pending three part Rack Motion Stabilization System (RMS). The rack slide tensioning position secures the drawer while in operation, while the Secure Stow Technology ensures the monitors do not move in transit. The Gas Shock Monitor Stabilizer coupled with the Multi Position Torque Hinges allow almost infnite monitor positioning. CVS, S-Video, Video inputs include aRGB, DVI-D, Component, HDMI & Optional HD-SDI.

The Standard Finish is Black Powder Coated Light Texture, but it can be customized to any color or logo.


Features

Enclosure:
• Mounts in standard 19-inch rack cabinets 26-36" depths
• Utilizes only 2RU (35")
• RSI Design (Rapid Start Installation). Installation takes Less than 5 minutes!
• Utilizes -Tech's Rack Motion Stabilization System (RMS) for use while in motion
• Telescoping front ears and rear arms with mounting hardware options for
Standard Rack, Transit Case, Flight Pack or Mobile Installations.
• Rugged all Aluminum construction for light weight applications and designed
to satisfy Broadcast, Industrial, Commercial, Military and Medical requirements

Display:
• Triple 17" Diagonal Active Matrix TFT LCD Displays
• 160 / 130 Viewing Angle
• WUXGA 1920 x 1200 @ 60 Hz
• Contrast Ratio 450:1, 340 NITS

Video Controller:
• Video which includes aRGB, DVI-D, CVS, S-Video, Component,
HDMI & Optional HD-SDI (See V09X, V04X & V03X
Controllers in the Video Controller Ref Guide)
• OSD (On Screen Display) Monitor Controls

Power:
• +12 VDC Operation via 110/220 power adapter
• Low Power Consumption

Other Features / Options:
• Dual 19" and Dual 17" Wide Monitors (1920x1200)
• Many different Video I/O Configurations
• HD/SD-SDI: (HD/SD-SDI via V03X/V09X Controller)
• Optional Touch Configurations
• Optional Dual Monitor KVM
• Optional Integrated Audio & speakers


LCD tilting to approximately 85 degrees.

Monitor Name:
17" Wide x 2 or x3
19" Production x2
Monitor Size
17"
19"
Display Type
WUXGA, Color, TFT-LCD, 2 CCFL BackLight
SXGA, Color, TFT-LCD, 4 CCFL BackLight
Max Resolution/Refresh
1920 x 1200
1280x1024
Aspect Ratio
16:10
4:3
Display Colors
16.8M
Brightness (Nits cd/m2)
340
300
Contrast Ratio
450
1000:1
Response Time (Tr/Tf) (ms)
30
8msGTG(Avg. Typ) 20ms(Typ, on/off)
Pixel Pitch (HxW)(mm)
0.191x 0.191
0.294 x 0.294
Power Management
EPA energy star, VESA compliance
Viewing Angle (Deg)
80L/80R/60U/70D
89/89/89/89 Typ.
MTBF (Hours)
30,000-50,000
Surface Treatment
Glare and hard-coating (2h) Low reflection
Hard-coating (3H), Non-Glare treatment,
Temperature Operating (C)
0 to +45
0 to +50
Temperature Storage (C)
-30 to +65
-20 to +60
Altitude Operating (Ft)
70 Kpa 48 Hours
10,000
Altitude Storage (Ft)
26 Kpa 48 Hours
30, 000
Humidity Operating (%RH)
5 to 90
5 to 90
Humidity Storage (%RH)
5 to 90
5 to 90
Applicable i-Tech Controllers:
V044, V044a,V034, V035, V036, V094, V095, V096, V097

Video Connections:
Analog RGB, DVI-D, S-Video, CVS, YPbPR, HD-SDI Input 4:2:2 via SDI & 4:4:4 via 3G SDI, SDI Loop Out, Audio
Chassis/ Drawer:
Mounting
Standard 19-inch rack
Slide Rails
Pre-integrated ball-bearing Slides with cable management guides.
Dimensions (WxHxD)
19 x 3.5 x 26-inch min. Can be installed in 26” - 36” Racks
Monitor Hinge
Heavy-duty Torque hinges to 60 lbs
Color
Black Powder coated with light texture (Custom colors available)
Weight (lbs)
48
