7U Rackmount LCD 15.6" LCD Monitor 250 nits VGA Input, Front OSD and Handle, VESA Mounting (Model: ERMW1560HD)

7U Rackmount LCD (3mm Metal Front Bezel),15.6" LCD monitor, 1920 x 1080, 250 nits VGA Input, Front OSD and Handle, VESA Mounting & Built in Power Supply

7U Rackmount LCD (3mm Metal Front Bezel),15.6" LCD monitor, 1920 x 1080, 250 nits VGA Input, Front OSD and Handle, VESA Mounting & Built in Power Supply

Inquiry/Quote Request
ERMW1560HD
  • Overview
  • Download

Features:
  • Modularize mechanical design provides flexible product configuration and easy maintenance.
  • Available with auto-brightness sensor offers application in day and night.
  • Optional build-in touch screen for interactive application.
  • VGA connector with optional AV, SV, AV-Looping
  • Complete custom design/solution for OEM customers

Specifications:
Panel         Cell Type / Glass Surface TFT LCD / Black Anti-Glare, low refection coating
Aspect Ratio / Size Wide / 15.6" viewable diagonal area
Active Area / Pixel Pitch 344.16(H) x193.59(V) mm / 0.1793(H) x 0.1793(V) mm
Native Resolution / Colors 1920(H) x 1080(V) / 16.7M
Brightness / Contrast 250 cd/m2 (typ) / 500 : 1
Response Time ≤ 12 ms
Viewing Angle (typical) H.90o (- 45o ~ + 45o) ,  V. 65o(- 40o ~ + 25o)
Light Source LED backlight, Long life, 35,000 hrs (typ)
Input Sources     PC System Signal Analog RGB (0.7/1.0 Vp-p, 75 ohms)
  Sync Separate Sync, Composite Sync, Sync On Green
  Frequency Fh : 30 - 82Khz , Fv : 50 -75Hz
Audio System 2W speaker x 2
Input Terminals 1 x VGA (15 Pin Female D-Sub) , 1 x PC Audio (Stereo Headphone Jack) , 1 x DC Power Plug
Convenient Features   Auto Calibration , Back Light Adjustment , Plug&Play (VESA DDC/CI, DDC 2B)
OSD Multi-Languages , Wall Mount Ready (VESA Dimension - please refer to Drawing)
Power Internal power supply with universal / Auto-Sensing, AC90 to 260V, 50/60 Hz
Power Consumption Operation / Power Saving 12.5 watt , < 1 watt (Support DPMS)
Operating Condition Temperature / Humidity 0oC ~ 50oC (32oF ~ 122oF) , 10% ~ 90% (no condensation)
Storage Condition Temperature / Humidity - 20oC ~ 60oC (- 4oF ~ 140oF) , 10% ~ 90% (no condensation)
Certification   FCC , CE
Dimensions   Physical Please refer to Drawing
Carton W x H x D = TBD
Weight N.W. / G.W. 4.5 Kgs / 5.5 Kgs
Container Loaded 20ft / 40ft / 40ft HQ

TBD (Sets , By pallet)



Options       Touch Video / TV Enhanced Panel Others
Resistive touch SV + AV Panel with LED backlight Digital Signage(Stand alone)
Capacitive touch

SV + AV + AV_Looping

High brightness panel Networking Digital Signage
SAW touch SV + AV + TV Wide Temperature Motion Sensor
Infrared touch   Sunlight Readable Light Sensor
Protected glass     Auto-Dimming
