Easy operation, time-saving
In 2002, cooperated with the technicians of Beijing TV Station, we successfully developed the world’s first Jib LCD monitors, which solved the problem of long distance focus, and quickly adopted by CCTV, many provincial & municipal TV stations. The prominent characteristics like high brightness and portability make it is much better than traditional CRT monitors. So far, iTechLCD jib monitors have become the standard products to match heavy type Jib Crane of top brand. Meanwhile, they’re widely used on large variety activities, Guangzhou Asia Games, Shenzhen Universiade and etc.

These monitors adopt 8mm thickness aluminum as bottom base, at the two sides of base, there are grooves could slide back and forth .			The stands on two sides are fixed by four screws to adjust balance between monitors and jib arms .
Besides, the metallic stands on two sides are designed with the dovetail trench for quick dismounting for the monitors and sunhood .			Beijing TV station (BTV) studio

A specially designed aluminum portable case is offered to fill in all the accessories like monitor, stands, power adaptor and etc.. It is not only easy to carry, but also protect the monitors from damaging efficiently.

Specification

Screen size	8.9”
Resolution	1280（H）x768（V）
Dot pitch	0.0505（H）x0.1515（V）mm
Aspect ratio	16:9 / 4:3 switchable
Brightness	400cd/m²
Contrast	800:1
Response time	12 ms
Viewing angle	H 170° / V 170°
Input voltage	DC12V
Voltage Range	DC 6~36V
Power consumption	≤20W
Unit dimension	L 309xH 393xD 256 mm
Weight	6.3 kg

Input&Functions

Model Function		RJ890HD	TL-890YSD	Remark
Video Input	composite	●	●	BNC x1 line 1.0 Vp-p±3 dB
	SD-SDI	●	●	BNCx2 line
	HD-SDI	●		BNCx2 line
	HDMI	●	●	HDMIx1 line
Audio Input		●	●	RCAx1 line（Dual Channels）
Audio monitoring		●	●	Rear speaker 2x0.5W（8Ω） Earphone：3.5mm (standard interface)
SDI embedded Audio		●	●	PPM / UV
Video output	composite	●	●	BNCx1 line Loopthrough7ΩAuto termination
	SD-SDI	●	●	BNCx1 line
	HD-SDI	●		BNCx1 line
TALLY		●	●	red/green two colors

RJ890HD Functions table

Signal Function		SDI1	SDI2	HDMI	COMPOSITE (CVBS)
Safety mark		●	●	●	●
Scaling	16:9,4:3 Auto	●	●	●	●
	Built-in scan，Overscan	●	●	●	●
	Pixel to Pixel	●	●	●	●
Color temperature D93、D65 Custom setting		●	●	●	●
Audio metering display		●	●
Red/Green two colors TALLY display（hardware）		●
blue only		●	●	●	●
black and white display		●	●	●	●

Function Sketch Front View

1 TALLY（indicator） 2 Power indicator（red） 3 Status locked indicator（green） 4 Sharpness / Pixel to Pixel 5 Saturation / Monochrom 6 Contrast / Volume 7 Brightness / Menu 8 Input signal switch 9 Safety ratio adjustment 10 4:3 / 16:9 Aspect ration switch 11 Shortcut key（User-defined） 12 Lock key / Menu exit 13 Headphone jack 14 Protection bar

Function Sketch Back View

15 Speaker 16 HDMI input 17 Composite input / output 18 Audio input 19 HD/SD-SDI output 20 HD/SD-SDI input 21 TALLY input 22 Power switch 23 DC 12V power input
