10.4" Full Aluminum Casing Fanless Panel PC w/ 5-wire Resistive Touch (Model: XIPC1040-ATB)

10.4" Full Aluminum Casing Fanless Panel PC w/ 5-wire Resistive Touch (Model: XIPC1040-ATB)

10.4" Full Aluminum Casing Fanless Panel PC w/ 5-wire Resistive Touch (Model: XIPC1040-ATB)

XIPC1040-ATB
  • Overview
  • Download

Features:


  • 10.4'' 500 nits 800 x 600 LCD with LED backlight
  • 5-wire Resistive type touch screen / (Option Capacitive Type)
  • Fan less system with INTEL® BayTrail-MN2930 SoC Processor (QC, 1.83GHz)
  • 2 * Gigabit LAN
  • Flexible expansion interfaces:
    1* MINI PCI-E
  • Four USB ports:
    3 x USB 2.0
    1 x USB 3.0
  • Four serial ports:
       3 x RS-232 (DB-9)
    1 x RS-232/422/485 (DB-9)
  • Digital signal input port: ^ 1x DVI input
  • IP 64 compliant system
  • RoHS compliance
  • Applications: Public Reception
       Transportation
    Government Agencies
    ATM / Kiosks / Touch Phones
  • 0°O + 60 °C Range operating temperature
  • VESA Mounting for Wall mounting 75x75 mm


Specifications:


LCD Panel Specification
Viewable Size Image 10.4” inch
Active Display Area 211.20 x 158.40
Pixel Pitch 0.264 x 0.264
Resolution 800X3 (RGB) X600
Contrast Ratio 500:1 (typ.)
Display Color 16.2M / 262K colors
Brightness 400 cd/m2 (typ.)
Viewing Angle U/D   60°/ 70°, L/F   70°/°
Recommend Resolution 800x600
Power Consumption 45W typical, normal operation
Touch (Optional) 5 -wires Resistive touch
System Specification
Form Factor 48 x 102mm 3.5” SBC Form Facto
Processor INTEL®   Celeron Processor BayTrail-MN2930
System Chipset INTEL®   Bay Trail SoC     Processor (QC, 1.83GHz)
System Memory 1* DDR3L1333/1066MHz SingleCH SO-DIMM up to 4GB
BIOS AMI 64Mb Flash ROM
Ethernet 2 * RTL8111E PCI-EVL Gigabit LAN /10/100/1000 Mbps
Audio Realtek ALC662HDAudio CODEC with 2-Channel
Serial 3 x RS-232, 1 x RS-232/422/485
USB 3* USB 2.0/1.1       / 1* USB 3.0
Storage 1 * Serial ATAII 3Gb/s connectors
Expansion Slots 1 * MINI PCI-E
Wall Mount 75*75 mm
Dimensions(W *H* D) 350 (W)x 290 (H)x 68(D) mm (TBD)
Operating Temperature -20 ~ 60°C
I / O       Interface 4 * USB 2.0/1.1 ports
2 * RJ-45 ports
1* Line-out port
1 * DVI-I port 1
1* 12V DC-IN JACK
3* RS232
1* RS232/422/485
1*Power Switch
