21.5" Waveform Studio LCD monitor 1920x1080, 1000:1, 2x HD/SDSDI, 1x HDMI, 1x CVBS input, 2x HD/SDSDI and 1x HDMI loop out, 1x HDMI converted to HD/SDI loop out, With waveform, RGB histogram, vector scope, focus assistant, blue only. (Model: SW2100C)

Features

• 21.5-inch LCD
• Full HD 1920×1080 resolution
• HD/SD-SDI, HDMI, Composite video
• Build-in HDMI converted to SDI output
• Waveform (Y/Cb/Cr/R/G/B), with full scale
• Vector scope
• R G B Histogram
• Peaking focus assist (red/blue switch)
• Audio meter (SDI 16-ch, HDMI 8-ch)
• SDI time code
• False color, Blue only, Zebra
• 3-color TALLY light
• Underscan / Overscan switch
• Video flip
• Customer editable video TITLE
• V-mount or Gold mount battery plate option
• Magnetic LCD protective glass


he SW2100C is a 21.5-inch HDSDI/HDMI studio LCD monitor, with a Full HD resolution 1920 ×1080 panel.
It integrates a wide range of professional functions including waveform, vector scope, RGB histogram, red/blue switchable peaking, focus assist, false color, blue only, zebra, rotate and flip, 16-ch SDI audio meter, time code, and internal color bars.

Waveform, vector, histogram, audio meter	Full scale waveform
Peaking focus assist	False color

The high quality LCD panels offers accurate color reproduction, The color calibration has been optimized in the new firmware, and users can adjust color temperature by RGB Gain and Bias.

Color Gamut	Color Temperature
RGB Balance	Gamma Luminance

The SW2100C accepts 2 HD/SD-SDI, 1 HDMI and 1 Composite video, and has 2 HD/SD-SDI loop through outputs, 1 HDMI loop through output, and 1 HDMI converted to SDI output.
It is powered via a 4-pin XLR 11-17V DC connector or V-mount / Gold-mount battery mounts, and goes with a Magnetic attached glass to protect the LCD screen.

Specifications

Input	2 BNC		(2) HD/SD-SDI in
	1 BNC		(1) Composite in
	1 HDMI		(1) HDMI in
	1 Audio 3.5mm jack		(1) Stereo analog audio in
Output	1 BNC		(2) HD/SD-SDI loop through out
	1 BNC		(1) HDMI converted to SDI output
	1 HDMI		(1) HDMI loop through output
	1 Audio 3.5mm jack		(1) Stereo analog audio output
	SDI	SMPTE-274M	1080i (60 / 59.94 / 50)
			1080p (30 / 29.97 / 25 / 24 / 23.98)
		SMPTE-RP211	1080psf (30 / 29.97 / 25 / 24 / 23.98)
		SMPTE-296M	720p (60 / 59.94 / 50)
		SMPTE-125M	480i (59.94)
		ITU-R BT.656	576i (50)
	HDMI		480I / 576I / 480P / 576P
			1080i (60 / 59.94 / 50)
			720p (60 / 59.94 / 50)
			1080p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98)
	Composite		PAL / NTSC
LCD panel	Size		21.5-inch
	Resolution		1920×RGB×1080
	Aspect ratio		16:9 (4:3 adjustable)
	Viewing angle		H/V: 178/178
	Brightness		250cd/m2
	Contrast		1000:1
Input Voltage			DC or battery 11V-17V
Rated power consumption			≤45W
Dimension			525×381×135mm
Net Weight			6.87kg
Working temperature			0℃～+40℃
Working humidity			10%～90%
Storage temperature			-15℃～+60℃
Storage humidity			10%～90%

Accessories

Accessory	Picture	Function
Power Adaptor		4-pin XLR adaptor.
Desktop Stand		Fixed stand feet.
Rotatable bracket		VESA mount rotatable bracket (Optional)
