Panel |
Cell Type / Glass Surface |
TFT LCD / Black Anti-Glare, low reflection coating |
Aspect Ratio / Size |
4:3 / 15" viewable diagonal area |
Active Area / Pixel Pitch |
304.13(H) x 228.10(V) mm / 0.297(H) x 0.297(V) mm |
Native Resolution / Colors |
1024(H) x768(V) / 16.2 Million |
Brightness / Contrast |
250 cd/m2 (typ) / 500 : 1 |
Response Time |
^ 12 ms |
Viewing Angle (typical) |
H. 130° (- 65° ~ + 65°) , V. 100°(- 55° ~ + 45°) |
Light Source |
CCFL , Long life, 50,000 hrs (typ) |
Input Sources |
PC System |
Signal |
Analog RGB (0.7/1.0 Vp.p, 75 ohms) |
Sync |
Separate Sync, Composite Sync, Sync On Green |
Frequency |
Fh: 30 - 82Khz , Fv: 50 -75Hz |
Audio System |
2W speaker x 2 |
Input Terminals |
1 x VGA (15 Pin Female D-Sub), 1 x PC Audio (Stereo Headphone Jack), 1 x DC Power Plug |
Convenient Features |
Auto Calibration , Back Light Adjustment, Plug&Play (VESA DDC/CI, DDC 2B) |
OSD Multi-Languages , Wall Mount Ready (VESA 75 x 75 mm) |
Power |
External AC-to-12VDC power adapter with universal / Auto-Sensing, AC 90 to 260V, 50 / 60 Hz |
Power Consumption |
Operation / Power Saving |
20 watt, < 2 watt (Support DPMS) |
Operating Condition |
Temperature / Humidity |
0°C ~ 50°C (32°F ~ 122°F), 10% ~ 90% (no condensation) |
Storage Condition |
Temperature / Humidity |
- 20°C ~ 60°C (- 4°F ~ 140°F), 10% ~ 90% (no condensation) |
Certification |
|
FCC,CE |
Dimensions |
Physical |
With Base(W x H x D): 356.9 x 340.8 x 185.0 mm |
Without Base(W x H x D): 356.9 x 279.0 x 40.5 mm |
Carton |
W x H x D = 419 x 380 x 142 mm |
Weight |
N.W. / G.W. |
4.0 Kgs / 5.0 Kgs |
Container Loaded |
20ft / 40ft / 40ft HQ |
TBD (Sets , By pallet) |
