3 x 3 Multi-Format Video Wall Processor (Model: ITEZW3300)

3 x 3 Multi-Format Video Wall Processor Cables are not included Box Dimensions (LxWxH) 22.0 x 16.0 x 10.0",Inputs: One HDMI, One VGA, One S-Video, One Composite, One Y/Pb/Pr,Supports Control via Ethernet, IR and RS-232 (Model: ITEZW3300)

Video
DVI Format	Single-link
Output Resolutions	Up to 1920x1080 (@60Hz)
Input Resolutions	Up to 1920x1080
Input Video Signal	1.2 volts
Input DDC Signal	5 volts
Outputs	(4) DVI-D, (1) AV Composite
Inputs	(2) HDMI, (1) VGA, (1) AV Composite, (1) AV Composite, (1) Y/Pb/Pr, (2) USB 2.0 Type A
Audio	(1) 3.5 mm input, (1) 3.5 mm output
HDCP Compliance	1.0/2.0
Controls
Front Panel	Tact Switches with OSD
RS-232	DB9 (female)
Remote	SAVI-RMT
Ethernet	RJ-45
Other
Power	100-240 V Internal
Power Supply Approvals	UL, CE, CSA, CEC, RoHS
USB Media Player
Type	USB 2.0 Type A
Video Formats	MJPEG, MPEG-1, MPEG-2, MPEG-4, Vvid, DivX H.264
Max Resolution	1920x1080 @30fps
Max Data Rate	20 Mbps
Audio Formats	MP3, WMA, AAC, MP2, PCM, AC3
Photos	Max resolutions: JPEG 15360x8640 BMP 9600x6400 PNG 9600x6400
Other	Max TXT resolution: 1200x800 Max ANSI/UNICODE GB/UTF8 file size: 1MB
Mechanical
Height	7.25 in.
Width	17.06 in.
Depth	7.25 in.
Weight	7.3 lbs
