IP54 front All in one PC Widescreen Display PC Panel Mount 42" LCD monitor, Intel Celeron CPU J1900 1.99GHz with IR touch (Model: BPM4200HDC2D-OT)

IP54 front All in one PC Widescreen Display PC Panel Mount 42" LCD monitor, Intel Celeron CPU J1900 1.99GHz solution  4GB Memory and 500GB HDD. With IP54 IR touch (Model: BPM4200HDC2D-OT)

IP54 front All in one PC Widescreen Display PC Panel Mount 42" LCD monitor, Intel Celeron CPU J1900 1.99GHz solution 4GB Memory and 500GB HDD. With IP54 IR touch (Model: BPM4200HDC2D-OT)

Main Feature

  • IP54-protected front panel
  • Intel-powered CPU
  • Widescreen display
  • Touch screen capability
  • WiFi access compatible
  • Low Power Consumption
  • Panel mount
  • Supports various I/O ports such as USB and LAN
BPM4200HDC2D-OT
  • Overview
  • Specifications
  • Download

iTech Company’s industrial all-in-one PCs are ruggedized touchscreen computers with an IP54-protected front panel. It is made of high quality industrial components for an enhanced performance and to be able to perform reliably in harsh conditions.

LCD Specifications
Viewable Size Image 42”(16:9)
Active Display Area(mm) 930.24(H) x 523.26(V)
Number of Pixels   1920 x 1080
Contrast Ratio 3000 : 1
Display Color 16.7 million
Brightness(cd/m)   350
Viewing Angle R/L178° x U/D178°
Recommended Resolution 1920 x 1080
Response time 6.5 ms
Life time 30,000/hr
Signal Input 1 x VGA,1 x DVI

Power
Power Input   110V~240V AC

Total Power Consumption

110W

Mechanical Specifications
Operating Temp. 0°~35°C
Relative Humidity 20~80% RH
Storage Temp. -20°~40°C
Dimensions(mm) 1016(L)x606(W)x117(D)
Mounting(LxW/mm) 600(L) x 200(W)
Color Black

Accessories
DVI Wire x 1
3.5” Audio Wire x 1
Power Core x 1


System Specifications
CPU Intel® ATOM J1900
RAM DDR3 SDRAM 4 G up to 16G
Storage 500G HDD / 120G SSD
USB Port 4 x USB 2.0 + 1 x USB 3.0 Port
PC Audio output       Realtek ALC662
Speaker Output 2 x 8 w internal speaker
LAN Port       1 x RJ-45 10/100/1000
WIFI IEEE 802.11b/g/n
Touch Screen Infrared Touch 6 points

Infrared Touch (Options)
-Windows 8/7/Vista /XP, MAC OS X, Linux, Android etc.
- Support panels of flat type for LCD.
