23.8" Military Grade IP65 Front Panel Mount LCD Monitor w/ VGA/HDMI/DP, PCAP Touch, 9~36V DC (Model: EMPMW238TCA1)

23.8" Military Grade IP65 Front Panel Mount LCD Monitor, 1920x1080, 250-nits LED, VGA/HDMI/DP, PCAP Touch, MIL-STD-810 & MIL-STD-461 compliant, 9~36V DC input.

23.8" Military Grade IP65 Front Panel Mount LCD Monitor, 1920x1080, 250-nits LED, VGA/HDMI/DP, PCAP Touch, MIL-STD-810 & MIL-STD-461 compliant, 9~36V DC input.

Inquiry/Quote Request
EMPMW238TCA1
  • Overview
  • Specifications
  • Download
The 23.8" Military Grade IP65 Front Panel Mount LCD Monitor is engineered for demanding defense, industrial, and mission-critical environments. Featuring Full HD 1920x1080 resolution, projected capacitive touch technology, and MIL-STD-810 / MIL-STD-461 compliance, this rugged display delivers reliable performance under shock, vibration, EMI, and harsh operating conditions. Its IP65-rated front bezel, wide viewing angles, and 9~36V DC power input make it an ideal solution for military systems, industrial automation, transportation, and outdoor applications.


Features:
  • Modular Mechanical Design: Enables flexible product configuration and simplifies maintenance.
  • Built-in PCAP Touch Screen: Ideal for interactive applications requiring precise input.
  • Auto-brightness sensor available, enabling optimal visibility in both day and night environments.
  • MIL-STD-810 (Vibration/ Shock)
  • MIL-STD-461 (EMI/EMC)
  • Built-In Speakers
  • Power 9~36V DC
Cell Type TFT LCD
Glass Surface Black Anti-Glare, low reflection coating
Aspect Ratio Wide
Size 23.8" viewable diagonal area
Active Area 527.04(H) x 296.46(V) mm
Pixel Pitch 0.2745(H) x 0.2745(V) mm
Native Resolution 1920(H) x 1080(V)
Colors 16.7M
Brightness 250
Contrast 3000 : 1
Response Time ≤ 16 ms
Viewing Angle (typical) H. 178°(- 89°~ + 89°) , V. 178°(- 89°~ + 89°)
Light Source LED backlight, Long life, 35,000 hrs (typ)

CERTIFICATION
FCC , CE
INPUT TERMINALS
1 x VGA, 1 x HDMI, 1 x DP, 1 x PC Audio (Stereo Headphone Jack) , 1 x DC Power Plug
CONVENIENT FEATURES
Auto Calibration , Back Light Adjustment , Plug&Play (VESA DDC/CI, DDC 2B) , OSD Multi-Languages , Wall Mount Ready (VESA Dimension - please refer to Drawing)
POWER
9~36V DC
POWER CONSUMPTION
Operation / Power Saving 13.4 watt , < 1 watt (Support DPMS)
OPERATING CONDITION
Temperature / Humidity -32°C ~ 55°C (25.6°F ~ 131°F), 10%~ 90% (no condensation)
STORAGE CONDITION
Temperature / Humidity -30°C ~ 80°C (-22°F ~ 176°F), 10%~ 90% (no condensation)
DIMENSIONS
Physical Please refer to Drawing
Carton W x H x D = TBD
WEIGHT
N.W. / G.W. TBD/TBD
CONTAINER LOADED
20ft / 40ft / 40ft HQ TBD (Sets , By pallet)
