22" Square LCD Monitor, 1920x1920, 500nits w/ HDMI, mDP, DC12V Input, AC100~240V Power Adapter (Model: SCSQ2200)
22" Square LCD Monitor, 1920x1920, 500nits, HDMI, mDP, DC12V input, AC100~240V Power Adapter, Operating Temp.: -5~50C, VESA mount
X
Inquiry/Quote Request
- Overview
- Specifications
- Download
| The 22-inch Industrial Square LCD Monitor (SCSQ2200) is designed for specialized applications requiring a unique square display. With a sharp 1920x1920 resolution, high brightness, anti-glare coating, and wide viewing angles, it delivers exceptional clarity and performance. Versatile mounting options, rugged durability, and multiple video interfaces make it perfect for industrial and commercial use. |
Features: |
|
| Display | Size/Panel Type | 22" TFT LCD Panel |
| Resolution | 1920 x 1920 | |
| Brightness (cd/m˛) | 500cd/m˛ | |
| Contrast Ratio | 1000:1 | |
| Response Time | 8ms | |
| Backlight | LED Backlight Unit | |
| Colors | 16.7M Colors | |
| Viewing Angle (H/V) | 178°/178° | |
| Surface Hardness | Anti-Glare, 3H | |
| Environment | Operating Temperature | -5°C~50°C |
| Storage Temperature | -20°C~60°C | |
| Humidity | 10%~95% RH(Non-Condensing) | |
| System | OSD | Menu, Auto, On/Off, Up, Down |
| I/O Interface | HDMI, mDP, DC IN | |
| Power Input | DC12V IN, w/ AC100~240V Power Adapter | |
| Power Consumption | 36W MAX. | |
| Compliance | FCC/CE/RoHS Compliance | |
| Mounting | VESA 100 x 100mm; 200 x 200mm | |
| Dimension/Weight | 414.56mm (W) x 414.56mm (H) x 60mm (D) / 6kgs |
