19" Rugged Military PC Intel 4th Gen Haswell i7-4650U 3.3GHz CPU (Model: Nmil-1900ZT01)
19" Rugged Military PC Intel 4th Gen Haswell i7-4650U 3.3GHz CPU (Model: Nmil-1900ZT01)
X
Inquiry/Quote Request
- Specifications
- Download
- Contact Sales
| LCD Panel |
| - LCD : 19” TFT LCD - Brightness : 350 cd/m2 - Resolution : 1280 X 1024 resolution |
| Touch |
| - 19” Projective Capacitive Touch - Resolution : 4096 x 4096 resolution |
| CPU, RAM, HDD |
| CPU : Intel 4th Gen Haswell i7-4650U up to 3.3GHz RAM : 8GB DDR3 RAM HDD : 1x 1 TB HDD + 1 x 256 GB SSD |
| I/O Port |
| - LAN : 2 x LAN - COM : 2 x RS232 + 2 x RS422 -Audio : 1 x Audio - USB : 2 x USB |
| Heater & Sensor – Optional items |
| - Built-in AC 50W Heater - Sensor : Below +6°C auto boot up ,above+16°C auto cut off |
| Military Connector |
| - All I/O connectors come with dust cap and mating connectors. |
| Power Supply |
| - 150W 90~264V AC-DC Power adapter |
| Mechanical |
| - Front Bezel : thick aluminum front bezel - Chassis : rugged steel construction |
| Mounting |
| - Support Front Panel Mount, 2 handles - Support VESA Wall Mount |
| Control Buttons |
| On-Off switch, Reset Switch, HD LED, Power LED |
| Power Consumption |
| - Total Power Consumption: around 30~40 watts excluding heater. |
| Environmental Test |
| - This Panel PC is design to meet the following Environmental Tests : |
| JSS-55555 |
| - Designed to meet JSS-55555 |
| EMI/EMC Test |
| - Designed to meet MIL-STD-461E |
| Vibration and Shock Test |
| - Designed to meet MIL-STD-810F Vibration and Shock Test standard. |
| Optional : Media Drive |
| 1 x DVD-RW in built |
