19" Rugged Full IP67 Panel PC, 1280x1024, 400nits, Intel Bay Trail N2930 1.83GHz w/ Aluminum Die?Casting Housing, VESA mount and Resistive Touch (Model: WRDPC1900-J-TR)
19" Rugged Full IP67 Panel PC, 1280x1024, 400nits, Intel Bay Trail N2930 1.83GHz w/ Aluminum Die?Casting Housing, VESA mount and Resistive Touch (Model: WRDPC1900-J-TR)
Main Feature
- Totally sealed Full IP67 Design
- High performance / low power Intel Celeron N2930 2.16GHz Processor
- Anti-scratch 19inch sunlight viewable 400 nits LCD panel (Optional for 1000 nits High Brightness)
- -10 to 60øC operating temperature
- Fanless, streamlined enclosure for highly efficient heat dissipation
- Touch screen control button to enable/disable touch screen interface
- Rugged Front Anti Impact Design
- Front control membrane keys Lockable by software
- Optical Bonding with Panel & Touch Screen to increase the clarity and transparence
X
Inquiry/Quote Request
- Specifications
- Download
- Contact Sales
| DISPLAY | ||||
| Resolution | 1280x1024 | Size | 19.0 inches | |
| Contrast Ratio | 1000:1 | Panel Brightness | 350 nits 1000 nits(Optional) |
|
| View Angles | 85,85,80,80 | |||
| Touch / Glass | Projected Capacitive Multi Touch Screen Bonding With Panel | Optional function | High brightness Panel for sunlight readable (Optional) | |
| SYSTEM SPECIFICATIONS | ||||
| Processor | Intel Celeron N2930 (2M Cache, up to 2.16 GHz) | Memory | 1 x SODIMM, DDR3L 1600 MHz, 4GB 8GB (Optional) | |
| Storage | 1 x mSATA SSD 64GB. mSATA SSD up to 512GB. (Optional) |
Ethernet controller | 2 x Intel Ethernet Controller I210AT | |
| Security | TPM 2.0 | Operating System | Windows 7 Embedded Systems (Optional) Windows 10 IoT Enterprise (Optional) Linux Ubuntu 18.04 (Optional) |
|
| WLAN | 802.11 a/b/g/n/ac (Optional) | BT | BT Support (Optional) | |
| ENVIRONMENT | ||||
| Operating Humidity | 10% to 90% (non-condensing) | Operating Temperature | -15øC ~ 55øC | |
| Storage Temperature | -30øC ~ 70øC | Shock | 30g for 18ms, 300m/sý | |
| Vibration | 1.60/1.96/2.18 g rms for XYZ / 5500Hz | IP rating | IP67 | |
| CERTIFICATION | ||||
| Certification | CE, FCC Class B MIL810F/ IEC60068227 For Vibration /Shock |
|||
| IO PORTS | ||||
| USB Port | 1 x M12 waterproof connector for 2 x USB2.0 1 x Waterproof USB TypeA Connector with cover |
Serial Port | 1 x M12 waterproof connector for RS232 | |
| Indicator | 1 x LED Indicator for power 1 x LED Indicator for storage 1 x LED Indicator for heater 1 x LED Indicator for LAN 1 x LED Indicator for lock touch |
LAN | 1 x waterproof Giga LAN RJ45 connector | |
| MECHANICAL | ||||
| Dimension | 474 x 410 x 111 mm | Mounting | VESA Mount / Yoke Mount | |
| Enclosure | Aluminum Housing | Coolingÿ System | Fanless Design | |
| Cut out | 462 x 386mm | |||
| CONTROL | ||||
| Button | 1 x Power Button 1 x Brightness up Button 1 x Brightness down Button 1 x Button for locking touch function 1 x Programmable function key |
|||
| ACCESSORIES | ||||
| Accessory | External open wire Power cable with waterproof connector External USB cable with waterproof connector External COM cable with waterproof connector External LAN cable with waterproof connector Waterproof caps RJ45 female-female converter Driver CD & Manual VESA screws |
Optional Accessory | 100~240V AC to DC Adapter with power cord (Optional) | |
