15" IP65 Front Panel Mount 1500nits, AR Glass, VGA, 12VDC w/ External 100-240VAC Power Adapter (Model: CPM1500IPHB2)
IP65 Front Panel Mount (Metal-3mm) 15" Industrial Panel / 1024x768 / 1500nits, clamp with VESA mount, AR glass with VGA and 12VDC with external 100-240VAC power adapter
CPM1500IPHB2
- Overview
- Specifications
- Download
| Panel |
Cell Type / Glass Surface |
TFT LCD / Black Anti-Glare, low reflection coating |
| Aspect Ratio / Size |
4 : 3 / 15" viewable diagonal area |
| Active Area / Pixel Pitch |
305.80(H) x 229.70(V) mm / 0.297(H) x 0.297(V) mm |
| Native Resolution / Colors |
1024(H) x 768(V) / 16.2 M |
| Brightness / Contrast |
1500 cd/m2 (typ) / 700 : 1 |
| Response Time |
< 35 ms |
| Viewing Angle (typical) |
H. 140° (- 70° ~ + 70°) , V. 120° (- 60° ~ + 60°) |
| Light Source |
LED backlight, Long life, 35,000 hrs (typ) |
| Power |
Power Input |
External 100-240VAC Power Adapter |
| Power Consumption |
30 Watt, <1 Watt |
| Operating Condition |
Temperature / Humidity |
0°C ~ 70°C (32°F ~ 158°F) , 10% ~ 90% (no condensation) |
| Dimensions |
Physical |
Please refer to Drawing |
| Carton |
W x H x D = TBD |
|
| |
| Options |
Touch |
Video / TV |
Enhanced Panel |
Others |
| Resistive touch |
SV + AV |
Panel with LED backlight |
Digital Signage(Stand alone) |
| Capacitive touch |
SV + AV + AV_Looping |
High brightness panel |
Networking Digital Signage |
| SAW touch |
SV + AV + TV |
Wide Temperature |
Motion Sensor |
| Infrared touch |
|
Sunlight Readable |
Light Sensor |
| Protected glass |
|
|
Auto-Dimming |
|
