12.1" Rugged Vehicle-Mount LCD with VGA, HDMI, 5-wire Resistive Touch (Model: WRD1210M9)

12.1" 400nits Rugged Vehicle-Mount LCD Anti-Corrosion Treatment with VGA, HDMI, 5-wire Resistive Touch

12.1" 400nits Rugged Vehicle-Mount LCD Anti-Corrosion Treatment with VGA, HDMI, 5-wire Resistive Touch

Inquiry/Quote Request
WRD1210M9-1
  • Overview
  • Specifications
  • Download
The WRD1210M9 12" Rugged Vehicle-Mount LCD Monitor with Resistive Touch is designed for mobile and industrial applications that require dependable display performance in demanding operating environments. Its compact 12-inch screen provides a practical viewing area for displaying operational data, navigation information, system status, and control interfaces in vehicle-mounted systems.

The WRD1210M9 is suitable for commercial vehicles, industrial transportation, warehouse equipment, fleet management, mobile workstations, and specialized vehicle control systems. Its vehicle-mount configuration supports integration into mobile computing environments, providing a practical display solution for applications that demand accessible controls and dependable visual information.


Features:
  • 12.1" Rugged Vehicle-Mount TFT LCD / 1280 x 800 / 400 nits / 1000:1 Contrast Ratio
  • 16:10 Aspect Ratio / VGA + HDMI Inputs
  • Isolated DC 9-36V Power Input / 3-Pin Terminal Block
  • Aluminum Housing with Anti-Corrosion Treatment / Fanless Design
  • Front IP65 Protection / VESA 75 x 75mm Mounting
  • Operating Temperature: -10°C to +55°C
  • 5-wire resistive Single Touch  touchscreen
I/O INTERFACE
Video Input 1x VGA
1x HDMI
Power Input 1x 10–60 V DC, 3-pin terminal block
Indicator 1x power LED, 1x status LED
OSD Buttons Power, Up, Down, ESC (Auto), Menu
LCD PANEL
Size 12.1" TFT LCD (16:10)
Resolution 1280 x 800
Brightness 400 nits
Contrast Ratio 1000:1
Display Color 16.2M colors
Viewing Angle 88° / 88° / 88° / 88° (L/R/U/D)
Active Area 261.12 x 163.2 mm
POWER
Input Voltage 9-36V DC Isolated Power Input

MECHANICAL AND ENVIRONMENT
Dimensions 310 x 215 x 48 mm (W x H x D)
Weight 2.8 kg
Enclosure Aluminum housing, anti-corrosion treatment
Cooling Fanless
Mounting VESA 75 x 75 mm (4x M6)
IP Rating Front IP65
Operating Temp. −10 °C to +55 °C
Storage Temp. −30 °C to +70 °C
Humidity 10%–90% RH, non-condensing
Vibration MIL-STD-810G Method 514.6 Procedure I (compliance)
Shock MIL-STD-810G Method 516.6 Procedure I (compliance)
Certification CE, FCC
