Successful Story



How the Touchscreen Outdoor Kiosks Revolutionize the QSR Industry


Nowadays, QSRs or quick service restaurants are making use of outdoor digital menu board kiosk solutions as part of their marketing campaign and daily operations. This enables a particular restaurant chain to advertise and promote their menu outdoors. With the advent of new technology, such solution is becoming a popular choice for many businesses all around the world. Take for instance, a particular touchscreen QSR drive thru in Africa, which transforms the typical customer experience as well as in driving profits for a certain business. There are a number of reasons on why businesses, particularly the QSRs, should adapt to this kind of technology.


Advantages of utilizing touchscreen outdoor kiosk solutions

Offers convenience to both business and the customers
Outdoor digital menu board kiosks offer better accuracy and more convenience to both the customers and the QSR owners as well. As customers line up in the drive-thru, they are able to see the menus being offered. With customers having great quick order dining experience, they will keep coming back to the business and this leads to more profit for the business.

Moreover, the touchscreen features change the regular drive-thru experience as customers can now simply press the buttons regarding their order. There’ll be a computerized system that facilitates the entire ordering process, allowing the customers to pick whatever they want.




Reduces the cost of the business
While being effective, the use of outdoor digital menu board kiosks will also reduce the overall marketing cost of the business. Other channels for advertising such as the newspaper and print media are becoming a thing of the past with this type of solution. This is now considered by many businesses as a great way to advertise.

Meanwhile, the printing cost of the business will also be significantly reduced. For example, if there’s a new menu, it can be displayed immediately. The same thing when there’s a change in the menu as the owner can simply change the digital signage instead of having the entire menu reprinted.


Opt for a reliable self-service kiosk solutions provider!
One of the top retailers of self-service kiosk solutions is the i-Tech Company. As quality outdoor kiosk and drive thru business must go hand in hand in catering to the needs of the consumers, choose a product that is built to last. Pick the one that is designed to withstand daily use and various weather conditions.


Check out the specifications of i-Tech Company’s product:
- IP65 Front Panel-Mount with OEM housing, Aluminum Bezel
- LCD Panel, 15"-1024x768, LED-1500nits, Wide Temp (-30~85 Degree)
- G150XG01V3, Wide temp Operating and Storage - 30C to 85C, Viewing angle H 80/80 V60/80
- VGA+DVI input ports
- 6mm Anti-Vandal protected glass, AR
- 2xFAN (High Speed fan) integrated on rear side
- Air flow between LCD panel and protected glass
- Auto-Dimming light sensor with 2ft loosed cable from I/O area
- Clamp Mounting
- Less Noisy Fans (GD126025LB)

Contact them today and ask for a quote on a touchscreen kiosk solution for your QSR outlet!


References:

Outdoor digital menu board kiosk For Outdoor QSR solutions, ArticlesBase.com
Outdoor Digital Advertising - Making It Cheaper, EzineArticles.com


24” Full HD Optical bonding with Projective Capacitive Touch Screen In-wall Application in Museum Part no. EPMW2400HD PCT


iTech has been a excellent supplier for California Science Center where this time we have installed our state of the art 24” Full HD 1920 x 1080 Panel mount portait LCD in “The Science Behind Pixas Exhinbition”.


The special unit of this installation is in the Museum where space is limited with Americans with Disabilities Act (ADA) requirement, customer has using this front bezel panel mount insert inside the dry wall. Only 3mm bezel is going out from wall make it just a like a pictures frame on the beautiful wall.


Another very unique features is, it is optically bonded the touch screen to the LCD to reduced reflection and provide Anti shock and vibration for the high traffice usuage on the touchscreen. Good features with optical bonding includes, higher clarity and Viewability, no air gap for dust and Moisture between the touch and LCD.


Project: Outdoor Portable interactive touscreen for HAWAII WILDLIFE CENTER information center


There are many ways you can use this outdoor LCD high brightness LCD with interactive touchscreen at semi outdoor exhibit like our ECH1900HB-SIP Rugged Completely Sealed Full IP66/NEMA4X Stainless Steel Chassis/Surface Mount, 19"  LCD monitor , 1280 x 1024, 1000 nits, with Glass, Auto Dimming control. It has been sucessfully installed at HAWAII WILDLIFE CENTER as a protable interactive digital Kiosk for presenting information to visitors understanding more about the wonderful Wild life world. If you need more information please feel free to contact us.

More product information is desk top mount 19" super sunlight readable LCD with working along with Brightsign player using EETI eGalax Touchscreen drivers. There are optional for single or double sign for outdoor lifestyle malls, transit stations for arrivial information, banks, and universities.

HAWAII WILDLIFE CENTER





12.1” 800x600, 1000nits LED Sunlight Readable High Brightness Wide Temperature -30ºC to 85ºC Rugged Industrial Open Frame LCD Monitor with VGA input (Model: YOP1210WTHB).


Very bright and reliable. We've used these outdoors in our trucker kiosks for years. With a quarter inch of glass and a small air gap, this was the only monitor we tested that did not fail in direct sunlight due to thermal isotropic loading. Please don’t ever stop making these…

Rated: 10 out of 10.

https://www.tideworks.com


Industrial Chassis/Wall Mount Metal Housing , 15.6" LCD monitor, 1366 x 768, 1000 nits LED Backlight, VGA+HDMI+3G SDI Input (Looping in and out),Side OSD,2) 9~36VDC water proof connector facing down.


Upon delivery, I tested this machine both indoors and outdoors and found it very useful for my crane applications. 16x9 15-inch monitor format is exactly what I need for my JonyJib: not too big, not too small.


It is very bright – I confirm it! (1000 nit as iTech claims). It is quite crisp and allows me to accurately focus and frame. It has sufficient viewing angle to control images. Certainly HDSDI in and out plus HDMI input.


While ordering, I knew that it will be missing some features like Peaking focus software function and some controls like zebra patterns or more sophisticated exposure controls, HDMI output, etc.


Nevertheless, ‘as is’ it is a truly great machine within a moderate budget and I am planning to use it extensively. I am convinced that iTech LCDs can be used for jib-arm applications, both: ‘as is’ or slightly modified..


John Huffman

http://www.jonyjib.com/


Industrial Chassis/Wall Mount Metal Housing , 15" LCD monitor, 1024 x 768, 1000 nits VGA Input, Side OSD


This company put this LCD inside the Fire truck, open up the side panel to use this high brightness LCD connecting to camera.


http://www.sutphen.com/


Rugged Completely Sealed Full IP66/NEMA4X Stainless Steel Chassis/Surface Mount, 55" LCD monitor , 1920 x 1080, 450 nits, with Glass, VGA and DVI input


i-Tech's Rugged Completely Sealed Full IP66/NEMA4X Stainless Steel Chassis/Surface Mount, 55" LCD monitor


Installed in Food processing Plant in USA.


32" Transflective Technology Sunlight Readable LCD Monitor with optical Bonding


i-Tech's Transflective Sunlight Readable 32" LCD monitor with Optical Bonding deployed at General Dynamics Information Technology.


This project is going to put this Rugged LCD Monitor under an extreme dessert harsh environment for testing. This mount is going to mount on the back of the military Truck hummer for display information.


Oct 2006



15"/17"/19" Panel Mount Touch Screen Deployed at Money Bus


i-Tech's state of the Art Panel Mount LCD Monitor with 3M Capacitive Touch Screen has deployed on high traffic Kids activities bus for interacting helpful learning materials with kids.


This durable SamSung LCD Panel combine with 3M capacitive touch screen provides the highest performance and long lasting touch screen display for kid to learn more about concepts of spending, giving and budgeting on this Money Bus.


March 2006



  Kids Count on the Money Bus program, a mobile financial literacy classroom for third through fifth grades, teaches children the concepts of earning, saving, spending, giving, budgeting and making sound financial decisions.

26" Industrial LCD replacing CRT in Airport Fl ight Information Display System


i-Tech's state of the Art 26" Chassis LCD Monitor wit h high contrast and high brightness has deployed at Airport for Flight Information Display System. Our capability to design and manufacture this excellent Industrial LCD for Public information display.

See below pictures for significant improvements to its flight information display system (FIDS), which displays airline departure and arrival information in the terminal building,


Dec 2006





Project: Rugged Completely Sealed Full IP66/NEMA4X Stainless Steel Chassis/Surface Mount, 46" LCD monitor , 1920 x 1080, 1000 nits, with Glass, VGA and DVI input + Additional Heater + Custom mounting bracket built with shock and vibration damper

Anti Shock and Virbration proof custom bracket for Industrial grade high brightness outdoor in-Vehicle or in-Truck installtion.  We have design this water and dust proof enclosures with custom mounting bracket, because there is so much shock and vibration in the command center trailer and in-Vehicle, with this design the LCD is safetly has been using since 2013 and continue on to provide a solid peformance on the many bumpy roads.

Using suspension mount on top

Shear mount at the both left and right hand side

Base mount at the bottom
