Case Outlook

1. Camera (optional)
2. Function keys (Vol+, Vol ‐, Up, Down, Exit)
3. Speakers
4. External WiFi antenna
5. VESA mount holes (100x100mm)
6. USB ports
7. RS232 x 2 (in RJ45 connector form)
8. Micro USB port
9. S/PDIF out
10. Headset+Microphone Jack
11. Ethernet RJ45 10/100Mbps connector
12. DC‐in 13. Power switch
14. LED (power indicator), IR receiver

Detail Specification

Hardware
CPU ‐ Cortex‐A9, Quad Core, up to 1.6GHz
System Memory ‐ 2GB DDR3 SDRAM Internal
Storage Memory ‐ 8GB~16GB eMMC
External Storage Memory ‐ SD Card (SDHC Class10 compatible)
LCD ‐ 21.5” 1920X1080 digital TFT LCD
Touch Panel Type ‐ 5 point capacitive multi‐touch type
Amplifier, Speaker ‐ Speaker unit: 3W+3W ‐ Amplifier 3W+3W ‐ Save the set‐up volume and keep the value at the time of power off and on.
Clock Battery (for RTC) ‐ Lithium‐ion non‐rechargeable coin battery
LED ‐ [power supply ON] , and [power supply OFF] modes are supported. ‐ Power supply ON: Red then turn Green after kernel boot up. ‐ Power supply OFF: LED light off
Wireless Communication Specification ‐ Wi‐Fi：IEEE 802.11b/g/n (optional) ‐ Bluetooth 4.0 (optional)
Ethernet Communication Specification ‐ 10/100Mbps LAN RJ45 built‐in
External Interface ‐ Key button (vol+、vol‐、Up、Down、Exit/Enter (when in recovery mode)) ‐ USB interface: USB host type A port （USB 2.0 high speed 480Mbpsx 2 Micro USB port （USB 2.0 OTG x 1 ‐ Ethernet RJ45 10/100Mbps connector x 1 ‐ RS232 x 2 (in RJ45 connector form) ‐ Power slide switch ‐ AC adapter port ‐ VESA mount (100x100 mm) ‐ Headset + MIC port ‐ S/PDIF out
Weight ‐ 6.365Kg (main body only, excluding AC adapter)
Housing Design ‐ Body and cover are in black color.
Housing Material ‐ Body: Metal
Power
‐ CE, FCC certified (pending)
‐ Power consumption: 1KHz audio playback etc. about 18W max., OFF 0W
‐ Input power spec.: AC 100‐240Vac, 3A max. 50‐60Hz, DC 12V±5%
Environmental Correspondence ‐ ROHS

Basic Specifications

Display	TFT LCD	21.5” (16:9 diagonal) inch configuration, 250 nits
	Number of Pixel	1920 (H) x 1080 (V)
	Back‐light	LED Side‐light type
Media format	Video	MKV, TS, FLV, AVI, VOB, MPG, DAT, ASF, RM, MOV, 3GP, MP4, WMV
	Audio	MP1, MP2, WMA, WAV, AAC, OGG, APE, FLAC
	Picture	JPG, BMP, GIF, JPEG, PNG
I/O	SD card slot	SD card (SDHC Class10 compatible)
	USB	USB 2.0 host type Ax2
	Micro USB	Micro USB 2.0 OTG x 1
	Add‐on Module Slot	N/A
Speaker	High quality speaker	3Wx2
Power	AC/DC adapter	12V/3A AC/DC adapter
Wireless Communication	Wi‐Fi	802.11 b/g/n (optional)
	Bluetooth	Bluetooth 4.0 (optional)
Ethernet	RJ45	10/100Mbps LAN
RS232	RS232	RS232 x 2 (in RJ45 connector form)
Camera	Front	Front: 2M pixels (optional)
Audio	Audio	Headset + microphone jack x 1
		S/PDIF out x 1
Function keys	Key button	Vol+ Vol ‐, Up, Down, Exit/Enter (when in recovery mode)
