 Features:
- Playback of digital video, graphic and text contents
- High quality digital and analog video output
- Supports direct connection to LCD
- Play list to control and schedule the playback
- IDE and USB ports for optional content storage
- Transfer all content over Ethernet
- Supports wireless LAN connection
- Fan less, compact PCB module
- Stereo audio function
| Specifications |
| Model Name |
WMSS100 |
WMSS200 |
| Dimensions |
7 1/8(W)x1 1/4(H)x4 3/8(D) inches
180(W)x34(H)x110(D)mm |
8 1/4(W)x1 3/8(H)x5(D) inches
210(W)x125(H)x34(D)mm |
| Weight |
Approx.0.6kg |
Approx.0.6kg |
| Storage Media |
CF(256MB,Optional with bigger capacity)
or 2.5"HDD(40GB)
(Need to be Linux ext2 format) |
CF(256MB,Optional with bigger capacity)
or 2.5"HDD(40GB)
(Need to be Linux ext2 format) |
| Content Update |
Networking(By Ethernet/WLAN)/USB Flash Drive |
Networking(By Ethernet/WLAN)/USB Flash Drive |
| Power Supply |
12V 1A DC input |
12V 1A DC input |
| Power Consumption |
Approx.5V,typical,normal operation
|
Approx.5V,typical,normal operation |
| Operation temperature |
0 to 40 Centigrade,Humidity 5-85%@40°C |
0 to 40 Centigrade,Humidity 5-85%@40°C |
| Video Format support |
MPEG1,MPEG2,MPEG4 |
MPEG1,MPEG2,MPEG4,WMV9 |
| Graphics Format support |
JPEG,BMP |
JPEG,BMP |
| Text Banner |
Variable scrolling speed and position |
Variable scrolling speed and position |
| Video Ouput |
DVI-I/VGA/S-Video/CVBS |
DVI-I/VGA/S-Video/CVBS |
| Audio Ouput |
Stereo RCA 2Wx2 |
Stereo RCA 2Wx2 |
| Network Connections |
10/100 Base-T(RJ-45)
mintPCI for 802.11b/g WLAN |
10/100 Base-T(RJ-45)
mintPCI for 802.11b/g WLAN |
| Group Management |
N/A |
Yes |
| Graphics in Portrait mode |
N/A |
Yes |
| RS232 control |
N/A |
Yes |
| Schedule |
Daily Schedule |
Weekly Schedule |
|
|
