Digital Signage LCD Frame Advertising Bulit in Media Player Commercial Grade Displays, Chassis/Wall Mount Metal Housing 55" LCD monitor, 1920x1080, LED-350nits,, HD output 1080P, CF / SD / USB Plug and Play,Built in Speakers, Output VGA x1, Remote Control, Side OSD. (Model: EDDW5500)

Digital Signage LCD Frame Advertising Bulit in Media Player Commercial Grade Displays, Chassis/Wall Mount Metal Housing  55" LCD monitor, 1920x1080, LED-350nits,, HD output 1080P, CF / SD / USB Plug and Play,Built in Speakers, Output VGA x1, Remote Control, Side OSD. (Model: EDDW5500)

Digital Signage LCD Frame Advertising Bulit in Media Player Commercial Grade Displays, Chassis/Wall Mount Metal Housing 55" LCD monitor, 1920x1080, LED-350nits,, HD output 1080P, CF / SD / USB Plug and Play,Built in Speakers, Output VGA x1, Remote Control, Side OSD. (Model: EDDW5500)

Main Feature

  • Digital Signage LCD Frame
  • Commercial Grade LCD with Metal housing
  • CF / SD / USB Plug and Play
  • High Definition Resolution 1920 x 1080
  • HD output 1080P
  • LED backlit
  • Play Video/Photo/Music
  • JPG,MP3,MPG1/2/4,AVI ,DIVX
  • Wide Viewing angle
  • Auto-Play, Auto-repeat
  • Support Timer to programming power on/off
  • Support play list to specify files to play
  • Support Programmable Photo Slide Timing
EDDW5500
  • Overview
  • Specifications
  • Contact Sales


Additional Features

- Support Disconnection Memory to continuously play where it break
- Power Resume : Continue play the content from break point after power recover
- Power on password Setting
- Photo Rotation
- Full Function Remote Control
- Built in Speakers
- Optional High brightness 1000nits
- Optional Motion Sensors and Dimming Sensors
- Optional 6mm Vandal Proof Safety Glass
- Optional Stainless steel Front Bezel
- Optional Anti-Reflective AR 3mm Front Glass for protection

  1. VGA Output Port
  2. USB Plugin
  3. CF Plugin
  4. SD Card Plugin



Panel         Cell Type / Glass Surface TFT LCD / Black Anti-Glare, low reflection coating
Aspect Ratio / Size Wide / 55" viewable diagonal area
Active Area / Pixel Pitch 1209.6(H) x 680.4(V) mm / 0.63(H) x 0.63(V) mm
Native Resolution / Colors 1920(H) x 1080(V) / 16.7Million
Brightness / Contrast 350 cd/m2 (typ) / 3000 : 1
Response Time ≦ 8 ms
Viewing Angle (typical) H. 178o (- 89o ~ + 89o) , V. 178o(- 89o ~ + 89o)
Light Source LED backlight, Long life, 35,000 hrs (typ)
Power Internal power supply with universal / Auto-Sensing, AC 90 to 260V, 50 / 60 Hz
Power Consumption Operation / Power Saving 280 watt , < 2 watt (Support DPMS)
Operating Condition Temperature / Humidity 0oC ~ 50oC (32oF ~ 122oF) , 10% ~ 90% (no condensation)
Storage Condition Temperature / Humidity - 20oC ~ 60oC (- 4oF ~ 140oF) , 10% ~ 90% (no condensation)
Certification   FCC , CE
Dimensions   Physical W x H x D = 1331.4 x 738.3 x 177.8 mm
Carton W x H x D = TBD
Weight N.W. / G.W. 43.5 Kgs / 46.5 Kgs
Container Loaded 20ft / 40ft / 40ft HQ TBD (Sets , By pallet)

Options       Touch Video/TV Enhanced Panel Others
Resistive touch SV + AV Panel with LED backlight Digital Signage(Stand alone)
Capacitive touch SV + AV + AV_Looping High brightness panel Networking Digital Signage
SAW touch SV + AV + TV Wide Temperature Motion Sensor
Infrared touch   Sunlight Readable Light Sensor
Protected glass     Auto-Dimming
