19" 1.3MP Versatile Clinical Review Color Display (Model: ERCD1913)

19" 1.3MP Versatile Clinical Review Color Display (Model: ERCD1913)

19" 1.3MP Versatile Clinical Review Color Display (Model: ERCD1913)

ERCD1913
  • Overview
Your Best Display Terminal for Various Modalities
Multiple video interfaces on the versatile ERCD1713 and ERCD1913 enable these systems to be interfaced with VGA, DVI, S-Video, Component and BNC displays. Adjustable color temperature settings make the ERCD1713 and the ERCD1913 perfect for endoscope applications. These systems are also easily interfaced to other advanced medical applications such as ultrasound devices and the 800:1 high-contrast ratio makes them perfect for viewing C-arm images.
 Features
17" & 19" color TFT LCD monitor
Multiple video inputs for connection with various medical devices
Auto-dimming function for optimized viewing conditions
Remote control for easy monitor set up
Picture-in-Picture display function
Smart software OSD control utility
Easy OSD keypad control
Optional touch screen
IP 64 waterproof and dustproof front bezel
MMC-1190C IO
Component Extend Cable Component to RCA VGA Cable Component to BNC
Component
Extend Cable
Component Cable
(Component to RCA)
VGA Cable
(VGA to BNC)
Component Cable
(Component to BNC)

       Perfect Image Viewing Terminal
Multiple Color Temperature Settings
A wide range of color temperatures are included in the ERCD1713 and ERCD1913, including 4200K/5000K/6500K/ 7500K/9300K. The easy color temperature adjustment ensure the best display quality when viewing images from different modalities.

Picture-in-Picture Function
PIP function enables a second images viewed in a small on-screen window. The optional Picture-outside-picture can be implemented for image comparison.

*Flexible PIP settings:
- Upper left/right and lower left/right of window's position
- Small, medium and large on-screen windows setting
- Independent brightness and contrast control for PIP windows

Auto-Dimming Function
The built-in ambient light sensor ensures the monitors perform optimally in all light conditions. The auto-dimming function extends backlight life time and provides comfortable viewing environment.

       Flexible Control Advantage
Smart OSD Utility
The smartOSD is an intelligent On-Screen Display control. The user-friendly OSD interface under Windows environment enables users to adjust the monitor easily from a remote system.
The smartOSD allows some functions as below:
• Power on/off
• Luminance selection
• Graphic card mode selection
• Gamma selection
• Monitor information
Smart OSD
Full-Function Remote Control Utility
Hot keys on the remote control include PIP zone, input source Selection, auto-dimming, brightness and contrast ratio. Remote control ensures easy configuration of the ERCD1713/1190C.

       Best Product Reliability
IP 64 Compliance
The IP 64 front panel is waterproof and dustproof, ensuring the best product reliability.

Paint-coating-free front bezel
The front bezel is no paint coating, enabling easy cleaning by disinfectant without harming the front bezel.

       Specifications
Model ERCD1713 ERCD1913 Model ERCD1713 ERCD1913
LCD size (inch) 17" 19" Audio
2 x 1~3W AMP
Resolution
1280 x 1024
OSD function
7 x buttons (On/off , Auto , Left , Up , Down , Right , Menu)
Brightness (cd/m2)
300
LED function
1 x LED on Front Panel for Power on/off
Contrast ratio
800:1 (typical)
1000:1 (typical) Power in
DC 12V in
Pixel pitch (mm)
0.294(H) x 0.294(V)
Power adapter
Medical Grade, AC 110V~240V to DC 12V
Viewing angle
160°(H)/160°(V)
178°(H)/178°(V) IP level
IP64 (for front panel)
Touch screen (optional)
Resistive 5-wire (RS-232 interface)
Preset Gamma
Gamma 2.2
Input video signal connector 1x Composite (NTSC/PAL)
1 x Component (YPbPr)
1 x S-Video
1 x VGA
1 x DVI-D
Mounting
Wall/Stand/ Arm mounting (VESA 100mm x 100mm)
Physical dimensions
(W x H x D) (mm)
428 x 350
x 65
469.94 x 382.46 x 67
Operation Temperature
0°C ~ 40°C
Storage
Temperature
-20°C ~ 60°C
DICOM
Meet DICOM standard
Remote control Auto-dimming & IR remote control function Safety & EMI
UL60601-1, EN60601-1, CCC, CE(EN60601-1-2), FCC Parts 18

       Ordering Information

Part No. Description
ERCD1713
1.3 Mega Pixel 17" Color Medical Monitor
ERCD1713/WT-R 1.3 Mega Pixel 17" Color Medical Monitor with touch screen RS-232 interface
ERCD1913 1.3 Mega Pixel 19" Color Medical Monitor
ERCD1913/WT-R 1.3 Mega Pixel 19" Color Medical Monitor with touch screen RS-232 interface


       Options

STAND Description
ERCD1713
1.3 Mega Pixel 17" Color Medical Monitor
ERCD1713/WT-R 1.3 Mega Pixel 17" Color Medical Monitor with touch screen RS-232 interface
       Packing List

Power cord (US x 1, EU x 1)
1 x Power adapter
1 x User manual and Driver CD
1 x Remote control
1 x Screw set
1 x Touch Panel RS-232 cable / Touch Pen /
Driver CD (WT-R model only)
1 x MMC Series medical LCD monitor
1 x DVI cable
1 x VGA cable (DB-15 to DB-15)
1 x VGA cable (DB-15 to BNC)
1 x Component cable (Mini Dim to RCA)
1 x Component cable (Mini Dim to BNC)
