High Brightness LCD 8.4" 620nits Open Frame Monitor (Model: WOPH840T1)

High Brightness/Transflective Sunlight Readable LCD 8.4" Open Frame LCD Monitor 620nits (Model WOPH840T1)

Overview
Download

Specification
Model Name	WOPH840T1
Viewable Size lmage	8.4"
Active Display Area (mm)	170.4(H)x127.8(V)
Pixel Pitch (mm)	0.213(H)x0.213(V)
Number of Pixels	800x600
Contrast Ratio	300:1
Display Color	262,144(6bit/colors)
Brightness (CD/m^2)	437.5
Viewing Angle (CR >=10)	-50~~50(H);-30~~60(V)
Synchronization Range Horizontal / Vertical	31.5~~48.1KHz/56~~75Hz
Recommended Resolution	640x480@60Hz, 75Hz
Signal Connector	15 pin D-sub
Power Soruce	AC 100~~240 V,Universal,±10%
Power Consumption	15 W typical, normal operation
Power Management	VESA DPMS Compliant
Plug & Play	VESA DDC 1/2B
Optional Video Input	S-Video,Composite
Optional DVI Input	No
Optional Touch Screen	SAW
Optional protection glass(refl ection rate<0.5%)	UV glass/clear type glass

Outdoor Readability
Ambient light(nit)	Brightness measure angle	10,000	30,000	80,000
Brightness gain (BL0n)(nit)	35°	437.5	620	1,180
Reflectance(net)(%)		1.2%	1.15%	1.16%

Remarks:WOPH840T1 series = VGA input only
WOPH840T1AV series = VGA + Video input

* Equivalent brightness under sunlight.

* Due to Panel material's deviation, different panel supplier will set different specific variance range to optical characteristics. The factors of time used, Lamp current, Ambient temperature will influence the optical measurements.
