10.4" Chassis Mount LCD Monitor with Projective Capacitive Multi-Touch, 1024x600, 200nits (Model: WCH1040-PCT)
10.4" Chassis Mount LCD Monitor with Projective Capacitive Multi-Touch, 1024x600, 200nits (Model: WCH1040-PCT)
X
Inquiry/Quote Request
- Overview
- Download
Features
• 10.4” 1024 x 768 Resolution• P-Cap Multi-touch Screen
Specifications
| Technical Description | |
| Model Name | WCH1040-PCT |
| Panel_Size | 10.4" |
| Active Display Area (mm) | 210.4 (H) x 157.8 (V) |
| Pixel Pitch (mm) | 0.2055 (H) x 0.2055 (V) |
| Panel_Display Resolution | 1024x768 |
| Panel_Brightness | 350 (typ.) |
| Panel_Contrast Ratio | 1200:1 (typ.) |
| Panel_Viewing Angle | -88~88 (H); -88~88 (V) |
| Number of Colors | 16.2M (6bits+FRC) |
| Touch_SensorType | Projective Capacitive Multi-Touch |
| Touch interface | USB |
| Mechanical Description | |
| Dimensions (W x L x H) (mm) | 252.4 x 198 x 36.4 (mm) |
| Power Information | |
| Power Source | 12V DC in, with External AC-DC Adapter(100~240V) |
| Power Consumption(Normal operation) | 15W typical, normal operation |
| Power Input | VESA DPMS Compliant |
| Display Signals | |
| Plug & Play | VESA DDC 1/2B |
| Video Input (optional) | N/A |
| DVI Input (optional) | Yes |
| *Due to Panel material's deviation, different panel supplier will set different specific variance range to optical characteristics. The factors of time used, Lamp current, Ambient temperature will influence the optical measurements. *Build in power is default |
