46" Refurbished NEC Large Screen LCD Monitor with PC & AV Inputs (Model: LCD4620-2-AV-R)

46" Refurbished NEC Large Screen LCD Monitor with PC & AV Inputs (Model: LCD4620-2-AV-R)

46" Refurbished NEC Large Screen LCD Monitor with PC & AV Inputs (Model: LCD4620-2-AV-R)

LCD4620-2-AV-R
  • Overview
Product discontinues. Call us at 888-483-2418.

Your digital signage applications will never look the same. The 46" NEC MultiSync LCD4620 available in both AV and IT versions, give your messages and images the "wow factor" they need to reach audiences with maximum impact. In addition to the exclusive Digital Signage Technology Suite, which boasts 20+ advanced features, this display touts an ultra-thin bezel for tiled-wall configurations, a built-in expansion slot that future-proofs it for emerging technologies and HD resolution that turns heads and draws crowds. Ultra-thin bezel design is ideal for video walls (up to 5 x 5).


Features:

  • Built-in expansion slot allows for seamless integration of future third-party components
  • Optional fully functional XP PRO single board computer processes your digital signage content and eliminates the need for an external PC, cabling, mounting and power supply
  • 2x2 LCD TileMatrix Video Wall Solution, which combines four LCD4020-2-AV displays with a mounting system, cabling and power suppression, provides an easy-to-configure, cost-effective solution for digital signage, information display and command/control applications
  • High-definition display provides optimal resolution (1366 x 768) for digital signage
  • Display management controls lower energy consumption and save money
  • Optional speakers, digital tuner and stand available
  • Optional digital tuner allows for high-definition television capabilities (LCD4620-2-AVT with installed tuner available by special order)

Specifications:

Display
Viewable Image Size 46"
Pixel Pitch 0.746mm
Pixels Per Inch 34 @ native resolution
Brightness 500/ 650 (max)cd/m2
Contrast Ratio 2000:1
Viewing Angle 178º Vert. 178º Hor. (89U/89D/89L/89R)@ CR>10
Response Time Rapid Response (8ms G-t-G)
Synchronization Range
Horizontal 31.5-91.1 KHz (Analog) /31.5-91.1 KHz (Digital)
Vertical 50, 60-85 Hz Analog/Digital
Input Signal
Video ANALOG RGB 0.7 Vp-p/75 Ohms; Separate sync: TTL Level; (Positive/Negative)
Sync Composite sync: TTL Level; (Positive/Negative); Composite sync on green: (0.3Vp-p negative 0.7Vp-p positive)
Input Connectors DVI-D, Analog D-Sub, Analog BNC (RGBHV), Composite (Shared RCA and BNC), S-Video, HDMI, Component (RCA), Audio 1 (minijack), Audio 2 and 3 Stereo (RCA), HDMI
Native Resolution 1366 x 768
Power Consumption
On 240W
Power Savings Mode <5W
Dimensions (WxHxD)
Net (with stand) 41.6 x 25.4 x 13.8 in./1056.6 x 645.2 x 350.3mm
Net (without stand) 41.6 x 24 x5.5 in./ 1056.6 x 609.6 x 140mm
Net Weight (with stand) 83.6 lbs. / 37.9 kg
Net Weight (without stand) 79.6 lbs. / 36.1 kg
VESA Hole Configuration Specifications 200 x 200mm (8hole) / 200 x 100mm (6 hole)
Environmental Conditions
Operating Temperature 5-40C/ 41-104F
Operating Humidity 20 - 80% (without condensation)
Operating Altitude 0 - 3000 m
Storage Temperature -20-60ºC / 14-140ºF
Storage Humidity 10-90%
Storage Altitude 12,000m / 39,370 ft.
Warranty 1 year
Additional Features Preimium PD Grade Sealed Panel, Advanced Cooling System for 24/7 operation; Expansion slot, ultra-thin bezel, programable lookup tables, Plug and Play (DDC/CI, DDC2B), PIP (remote), POP, 6-axis color adjustment,multi-level programmable zoom, CableComp, TileMatrix (5x5), TileComp, video ready, scheduler (w/ RTC), sharpness/softness, off-timer (countdown), screen saver, vacation switch, 10-bit gamma, AutoBright (signal input), Windows Vista-certified, portrait-capable; Kensington Lock; closed captioning
