Chassis, Wide 25.5" LCD monitor, 1920 x 1200, 350 nits with 6mm SAW Touch (Model: ECHW2550-SWG)

Chassis, Wide 25.5" LCD monitor, 1920 x 1200, 350 nits with 6mm SAW Touch (Model: ECHW2550-SWG)
  • Front View
  • Front View
  • Front View
  • Side View
  • Side View
  • Back View
  • Accessories View

Chassis, Wide 25.5" LCD monitor, 1920 x 1200, 350 nits with 6mm SAW Touch (Model: ECHW2550-SWG)

Inquiry/Quote Request
ECHW2550-SWG
  • Overview
  • Download
Product discontinues. Call us at 888-483-2418 for replacement item.

Features:
  • Modularize mechanical design provides flexible product configuration and easy maintenance
  • Optional panel with ultra high brightness and super dynamic contrast, along option with auto-brightness sensor offers application in day and night.
  • Optional build-in touch screen for interactive application

Specifications:

Panel Cell Type / Glass Surface TFT LCD / Black Anti-Glare, low reflection coating
Aspect Ratio / Size Wide / 25.54" viewable diagonal area
Active Area / Pixel Pitch 550.08(H) x 343.80(V) mm / 0.2865(H) x 0.2865(V) mm

Native Resolution / Colors

1920(H) x 1200(V) / 16.7 Million
Brightness / Contrast 350 cd/m2 (typ) / 1500 :1
Response Time s 8 ms (G-to-G)
Viewing Angle (typical) H. 178° (- 89° ~ + 89°) , V 178°(- 89° ~ + 89°)
Light Source CCFL , Long life, 50,000 hrs (typ)
Input Sources PC System Signal Analog RGB (0.7/1.0 Vp.p, 75 ohms)
Sync Separate Sync, Composite Sync, Sync On Green
Frequency Fh: 30 - 82Khz , Fv: 50 -75Hz
Audio System 2W speaker x 2
Input Terminals 1 x VGA (15 Pin Female D-Sub), 1 x PC Audio (Stereo Headphone Jack), 1 x AC Inlet
Convenient Features Auto Calibration , Back Light Adjustment, Plug&Play (VESA DDC/CI, DDC 2B)
OSD Multi-Languages , Wall Mount Ready (VESA 400 x 200 mm)
Power Internal power supply with universal / Auto-Sensing, AC 90 to 260V, 50 / 60 Hz
Power Consumption Operation / Power Saving 95 watt, < 2 watt (Support DPMS)
Operating Condition Temperature / Humidity 0°C ~ 50°C (32°F ~ 122°F), 10% ~ 90% (no condensation)
Storage Condition Temperature / Humidity - 20°C ~ 60°C (- 4°F ~ 140°F), 10% ~ 90% (no condensation)
Certification   FCC,CE
Dimensions Physical With Base(W x H x D): TBD
Without Base(W x H x D): 620.0 x 414.0 x 93.0 (mm)
Carton W x H x D = TBD
Weight N.W. / G.W. 12.0 Kgs/13.5 Kgs
Container Loaded 20ft / 40ft / 40ft HQ TBD (Sets , By pallet)

Options Touch Video / TV Enhanced Panel Others
Resistive touch SV + AV Panel with LED backlight Digital Signage(Stand alone)
Capacitive touch

SV + AV + AV_Looping

High brightness panel Networking Digital Signage
SAW touch SV + AV + TV Wide Temperature Motion Sensor
Infrared touch   Sunlight Readable Light Sensor
Protected glass     Auto-Dimming
