5U 10.4 SVGA, Video + 4x 2 screens Rack Mount Serial Monitor (Model: LMR5240)

5U 10.4 SVGA, Video + 4x 2 screens Rack Mount Serial Monitor (Model: LMR5240)

5U 10.4 SVGA, Video + 4x 2 screens Rack Mount Serial Monitor (Model: LMR5240)

LMR5240
  • Overview
  • Download

Features:

10.4″ LCD Screen:
• 10.4″ TFT LCD Screen
• 1 VGA RGB Input • 1 Video Composite Input
• 1 Video S•Video Input
• 2 Audio Inputs (RCA L/R or 3.5mm Stereo Jack)
• 1 Audio Output (3.5mm Stereo Jack)
• OSD Menu / Up/Down / Auto and Power control


Specification:

DISPLAY SCREEN
LCD SIZE: 10.4 INCH
ACTIVE AREA: 211.2(W)x 15834mm (H)
ELEMENT: COLOR TFT LCD
RESOLUTION: 800 x 600 SVGA
DOT PITCH: 0.264 (W) x 0.264 (H)mm

POWER SOURCE
DC 12V

POWER CONSUMPTION
10W Typ.

OPERATING TEMPERATURE
0℃ ~ 50℃

STORAGE TEMPERATURE
-20℃ ~ 60℃

BRIGHTNESS
230 cd/m2

CONTRAST RATIO
500:1

OPTICAL RISE TIME / FALL TIME
10/25 Typ.


RESPONSE TIME
10 ms

VIEWING ANGLE
Vertical +35∘/-65∘, Horizontal : 60∘

PC INPUT
RGB Analogue Input 15 Pin D-sub x 1

VIDEO INPUT
1 VP-P 75Ω , RCA x 1 , S-Video x 1

PLUG AND PLAY
VESA DDC2B

GREEN FUNCTION
VESA DPMS

OSD CONTROL FUNCTION
Brightness, Contrast, Color, Volume, Mute

DIMENSION (W x H x D)
489.0 x 220.0 x 51.0 mm

WEIGHT
3500 10 g



Features:

4″ LCD Screen:
• 2 X 4″ LCD Screens
• 2 Video BNC Inputs
• 1 Video BNC Output
• Individual brightness / contrast control for each screen
• Tilt adjustment for optimum viewing angle
• Heavy duty metal housing
• Universal power supply


Specification:

DISPLAY SCREEN
SIZE: 4 INCHES ( 10 cm)
ACTIVE AREA: 82.1(W) x 61.7 (H)
ELEMENT: COLOR TFT LCD
RESOLUTION: 480(W)X234(H)
DOT PITCH: 0.171(W) x 0.264 (H)

VIDEO SYSTEM: NTSC and PAL Auto-switch
NTSC PAL
f H : 15.75 Khz f H : 15.625 Khz
f V : 60 Hz f V : 50 Hz
f c : 3.58 MHz f c : 4.43 MHz

VIDEO INPUT
1Vpp 75 Ohm

POWER CONSUMPTION
12V, 250 mA , 3W Max.

POWER SOURCE
DC 12V

CONTRAST
150 : 1

BRIGHTNESS
250 cd/m2

VIEWING ANGLE
Vertical +30 / -10, Horizontal 45

RANGE OF OPERATING VOLTAGE
DC 9 ~ DC 13V

OPERATING TEMPERATURE
0℃ ~ 60℃

STORAGE TEMPERATURE
-20℃ ~ 80℃

LCD SCREEN
96.35 X 77.00 X 11.30 (mm)

CONTROL FUNCTION
Adjust Brightness / Contrast
