9" 3G SDI & HDMI LCD monitor 1280x768, 800:1, 1x 3G-HDSDI, 1x HDMI and 1x CVBS input, 1x 3G-HDSDI, 1x HDMI and 1xCVBS loop through out; 1x L/R Stereo audio input; image 180° rotate, With Carry Case. (Model: SW0890SD)

Features

• 9-inch LCD
• 1280Ă—RGBĂ—800
• 16:9 / 4:3 adjustable
• 3G/HD/SD-SDI, HDMI, Composite video, Stereo audio
• SDI embedded audio output via 3.5mm earphone socket and speaker
• Front and rear 3-color TALLY light
• Underscan / Overscan switch
• Canon DLSR scale zoom-in
• Video flip
• Customer editable video TITLE


SW0890SD is a 9-inch 3G/HD/SD-SDI/HDMI on-camera monitor with 1280 x 800 resolution and 700:1 contrast. It supports 3Gbos SDI, and SDI embedded audio output via earphone. It has front & rear dual TALLY light, Canon DSLR scale zoom-in, video flip, customer editable video title, and safety mark display.
SW0890SD accepts 3G/HD/SD-SDI, HDMI, Composite video input and loop through output, and 1 stereo audio input.

Specifications

Input	1 BNC		3G/HD/SD-SDI in
	1 BNC		Composite in
	1 HDMI		HDMI in
	2 RCA		L, R stereo audio in
Output	1 BNC		3G/HD/SD-SDI loop through out
	1 BNC		Composite loop through out
	1 HDMI		HDMI in
	3.5mm headphone		SDI, HDMI, Analog audio out
Signal format	SDI	SMPTE-425M	1080p (60 / 59.94 / 50)
		SMPTE-274M	1080i (60 / 59.94 / 50)
			1080p (30 / 29.97 / 25 / 24 / 23.98)
		SMPTE-RP211	1080psf (30 / 29.97 / 25 / 24 / 23.98)
		SMPTE-296M	720p (60 / 59.94 / 50)
		SMPTE-125M	480i (59.94)
		ITU-R BT.656	576i (50)
	HDMI		480I / 576I / 480P / 576P
			1080i (60 / 59.94 / 50)
			720p (60 / 59.94 / 50)
			1080p (60 / 59.94 / 50 / 30 / 29.97 / 25 / 24 / 23.98)
	Composite		PAL / NTSC
LCD panel	Size		9-inch
	Resolution		1280Ă—RGBĂ—800
	Aspect ratio		16:9 (4:3 adjustable)
	Viewing angle		H/V: 140/120
	Brightness		250cd/m2
	Contrast		700:1
Working Voltage			DC or battery 6.5V-17V
Rated power consumption			<16W
Dimension			236Ă—170.5Ă—47.5mm
Net Weight			970g
Working temperature			0℃～+40℃
Working humidity			10%～90%
Storage temperature			-15℃～+60℃
Storage humidity			10%～90%

Accessories

Accessory	Picture	Function
Sun Hood		LCD sun light hood, made of Nylon.
Carrying Case		Nylon, strong and high quality. (Optional Purchase)
Power Adaptor		2-pin power adaptor
Protecting film		Protecting film for LCD panel.
HDMI cable		Mini HDMI to Standard HDMI cable (optional purchase)
Stand		Cold shoe stand.
