Industrial Open Frame Metal Housing High Brightness Wide 19" LCD 1440x900 1500nits, 800:1, 80/80/80/80, Power Consumption 35W with VGA and DVI input (Model: YOPW1900HB)

Industrial Open Frame Metal Housing High Brightness Wide 19" LCD 1440x900 1500nits, 800:1, 80/80/80/80, Power Consumption 35W with VGA and DVI input (Model: YOPW1900HB)

Industrial Open Frame Metal Housing High Brightness Wide 19" LCD 1440x900 1500nits, 800:1, 80/80/80/80, Power Consumption 35W with VGA and DVI input (Model: YOPW1900HB)

Overview
Download

Feature:

Sunlight Readable.

LED Backlight.

19" LCD with resolution up to 1440 x 900.

Suitable for military, tablet, ruggedized PC, kiosk, advertising, POS, marline, transportation, gaming, gas pump.

Specifications:

Panel Type	19-inch TFT LCD
Screen Diagonal	19-inch
Active Display Area (mm)	408.24 (H) x 255.15(V)
Pixel Pitch (mm)	0.2835x 0.2835
Number of Pixels	1440x3(RGB) x 900
Contrast Ratio	800:1
Color Arrangement	R.G.B. Vertical Stripe
Brightness (cd/m²)	1500 cd/m²
Viewing Angle(Typ.)	80/80/80/80 (R/L/U/D)
Signal Connector	15 PIN D-Sub, DVI-D
Power Source	AC100 ~ 240V, Universal +/- 10%
Power Consumption	35W (MAX)
Power Management	VESA DPMS Compliant
Operating Temperature	0 ~ +50°C
Storage Temperature	-20 ~ +60C
Plug & Play	VESA DDC 1/2B
