The largest industrial 4:3 aspect monitor size that iTechLCD carries is the FOP1900, 19 Inch LED open frame monitor.  Although the unit has a large display area, the unit itself, takes up relatively little space and leaves behind a smaller footprint than its counterpart desktop displays.

Where can the FOP1900 be used?  Since the 19” open frame monitor has a brightness of 350 nits from using an LED backlit panel, the screen is brighter than most can be used for indoor environments and some outdoor environments or places that have higher ambient lighting than most.

Will the design ever change for industrial monitors?  Even with constant design changes and revisions to LCD panels, iTechLCD’s engineers will always ensure that the display area remains consistent without having to modify the mechanical dimensions of the overall unit chassis itself.  We ensure that the mechanical dimensions will remain consistent throughout the lifetime of the monitor.

With a larger screen size, the FOP1900, 19” LED open frame monitor is designed to be integrated into various applications such as Kiosks, instrumentation displays, control panels and other various industrial applications.

FOP1900 Open Frame Monitor Quick Facts

• 4:3 Aspect, 1280 x 1024 resolution
• 376.32 x 301.06 [mm] x [mm], 14.81 x 11.85 (inch) x (inch) active area
• High grade TFT, 350 nit LCD Panel
• Standard 15-pin VGA input connector
• DVI, Composite and BNC video input options

Standard Features

• Compatible with iTechLCD's standard definition signage players
• Robust CNC milled open frame enclosure
• Compliant with RoHS, UL, CSA, TUV, FCC B, VCCI B, CE TCO 99, TUV Ergo, EPA Energy Star
• Perfect for kiosk, equipment and instrument drop-in designs
• Superior viewing angles, contrast ratio and brightness
• Unique design accounts for heat ventilation

Included in the package

• FOP1900, 19 Inch Open Frame Monitor
• +12V power adapter and cord
• VGA cable

Specifications
