17" Rackmount KVM Drawer with High Density USB VGA KVM Switch - CAC Card Reader Compatible, upto 4 USB computers from 1RU of rack space. (Model: TNK1174e-CR)

17" Rackmount KVM Drawer with High Density USB VGA KVM Switch - CAC Card Reader Compatible, upto 4 USB computers from 1RU of rack space. (Model: TNK1174e-CR)

17" Rackmount KVM Drawer with High Density USB VGA KVM Switch - CAC Card Reader Compatible, upto 4 USB computers from 1RU of rack space. (Model: TNK1174e-CR)

TNK1174e-CR
  • Overview
  • Download

Features & Applications


The TNK117 USB KVM Drawer with Built-in High Density USB KVM Switch combines a rackmount LCD monitor, keyboard, touchpad mouse and a 4-, 8- or 16-port high density USB KVM switch in a space-saving 1RU industrial strength drawer.
  • Forward-folding 17" TFT/LCD VGA monitor.
    • 1280x1024 video resolution.
    • Tilt LCD up and back to adjust to any comfortable viewing angle to 120°.
  • Control up to 16 USB computers (PC, SUN, and MAC) with VGA video.
  • Available with optional USB port to connect an external USB device, such as a CAC card reader or flash drive.
  • Torque-friction hinges - monitor does not wobble, spring, or slam shut.
  • Compact, heavy-duty tactile keyboard with large padded wrist-rest.
  • LCD auto-shutoff in closed position.
  • Drawer locks into place when open to prevent it from sliding out of the rack.
    • Front quick-release latches for pushing the drawer back into the rack.
  • Dedicated microprocessors prevent CPUs from locking up, ensuring reliable control.
  • Keyboard available in multiple languages: English(US), English(UK), German, Italian, French, and Spanish.
  • Cabling runs are simplified with iTech's high density KVM switch cables.
  • Available with Sunlight Readable monitor - call an iTech Product Consultant for more information.


Specifications


Power
  • 110 or 220 VAC at 50 or 60 Hz via IEC connector. (Country-specific power supply cable included.)
Dimensions
  • WxDxH (Inches): 19x23.9x1.75.
    • Handle adds an additional 1.5" to the depth when monitor is in closed position.
  • Drawer is adjustable to various rack depths from 24" deep to 40" deep.
  • Drawer locks into place when open to prevent it from sliding in and out of the rack.
  • Rack ears are available for two post style telco rack mounting, select part number RL-T15-TEL.
Regulatory Approvals
  • CE, RoHS
Environmental
  • Operating temperature: 32°F to 104°F (0°C to 40°C).
  • Storage temperature: -4°F to 140°F (-20°C to 60°C).
  • Operating and storage relative humidity: 20 to 90% non-condensing RH.
Warranty
  • Two year


Diagram


Rackmount USB KVM Drawer Application with USB KVM Switch

Rackmount USB KVM Drawer Application with USB KVM Switch
