RMT-170e-SD

17" LCD Video Monitor with SD-SDI input/output, VGA/DVI-D/HDMI input and analog audio inputs and outputs. (Model: RMT-170e-SD)

17" LCD Video Monitor with SD-SDI input/output, VGA/DVI-D/HDMI input and analog audio inputs and outputs. (Model: RMT-170e-SD)

RMT-170e-SD
  • Overview
17” LCD, dual SD-SDI inputs with loop through, 16:9 widescreen Multi Interface LCD Monitors.

Specifications:

Rack Height: 6RU
Dimensions: 12.1X16.3X2.8" (308X415X72MM) - WITHOUT STAND OR RACK-MOUNT
Power Consumption: 40W
Signals Monitored: SD-SDI
SDI Inputs: 2 SD-SDI VIDEO INPUTS ON BNC (1 PER SCREEN); 1 CONFIGURABLE DVI-I VIDEO INPUT (DVI-D, VGA OR HDMI)
SDI Input Termination: 75 OHMS (BNC - UNBALANCED)
SDI Outputs: 1 RESHAPED AND RECLOCKED SD-SDI VIDEO OUTPUTS OF SELECTED SDI INPUT ON BNC
Level Meters: ON-SCREEN FOR UP TO 8 OF 16 CHANNELS
Level Meter Dynamics: VU OR PPM OR BOTH
# of Displays: 1.0
Display Size: 17.0 IN DIAGONAL
Display Modes: NTSC/PAL AUTO RECOGNITION
Viewing Angle: 70 DEGREES LEFT/RIGHT; 70 DEGREES UP; 20 DEGREES DOWN
Aural Sound Outputs: INTEGRATED LEFT AND RIGHT SPEAKERS; 1/8" STEREO HEADPHONE JACK, MUTES SPEAKERS
Other Features (1): LOCAL CONTROL (VIA MENU OPERATION) FOR: SAFE AREA, SAFE TITLE, CENTER MARKERS, H/V DELAY, WAVEFORM,
Supplied Accessories: AC POWER ADAPTER (110-220VAC TO 12 VDC) WITH EIA REGION APPROPRIATE POWER CORD.
