15" Sunlight Readable LCD LED Panel with Driver (Model: JPD1500HB-A).

15" Sunlight Readable LCD LED Panel with Driver (Model: JPD1500HB-A).

15" Sunlight Readable LCD LED Panel with Driver (Model: JPD1500HB-A).

JPD1500HB-A
  • Overview
  • Download
Product discontinues. Call us at 888-483-2418 for replacement item.

Features

  • Sunlight Readable
  • High Contrast Ratio
  • Wide Temperature
  • Low Power Consumption
  • Optional Touch Systems
  • VGA to XGA

Specifications

Display Type LCD + LED Driver
LCD Display 15" TFT LCD Module
Base Panel Supplier AUO
Base Panel Model M150XN07
Display Color 6-bits, 16.2M colors
Display Area 304.128 x 228.096 mm
Brightness 1,000 nits
Resolution 1024 x 768 (XGA)
Contrast Ratio 700 : 1
Pixel Pitch (mm) 0.297 x 0.297
Viewing Angle 80º/80º(H) 70º/60º(V)
Response Time 8ms (Tr+Tf)
Sync LVDS
Power Consumption TBD
Temperature Operation 0°C~+50°C
Storage -20°C~+60°C
Dimension(WxHxD)mm 326.50 x 253.50 x 12.00
Lamp Lifetime (HR) 50,000
Control(AD) Board (Optional) None
OSD Button None
OSD Menu Brightness Contrast H/V Position Color Phase Clock…
LED Driver JL150
Weight 1,010 g
Optional Transflective tech
Glass Bonding
Touch
Specifications are subject to change without notice
Control(AD) Board (Optional) Standard VGA + DVI + Audio(Option)
Option VGA + DVI + Composite + S-Video + Audio(Option)
OSD Button 5 Key Power Switch Select(+,-) Down Up Menu
