12.1" Panel PC Ultra Low Power with Atom D2550 1.86GHz Dualcore Processor -25~+55°C Wide Range Operating Temp (Model: WRDC0120CT)

12.1" Panel PC Ultra Low Power with Atom D2550 1.86GHz Dualcore Processor -25~+55°C Wide Range Operating Temp (Model: WRDC0120CT)

12.1" Panel PC Ultra Low Power with Atom D2550 1.86GHz Dualcore Processor -25~+55°C Wide Range Operating Temp (Model: WRDC0120CT)

WRDC0120CT
  • Overview
  • Download

Features:

  • Ultra Low Power Atom D2550 1.86GHz Dual-core Processor
  • 4 Wire resistive touch screen
  • -25~+55°C Wide Range Operating Temperature
  • Anti-Corrosion housing with Fanless Design
  • 9V~36V DC Isolation Wide Range Power (default)
  • Optional 6-60V DC Input, and Optional for Ignition On/Off delay
  • Anti-Shock & Vibration compliant with MIL-STD-810F
  • Compliant with EN50155


Specifications:


Display Characteristics
Panel_Size 12.1"
Panel_Display Resolution 1280x800
Pixel Pitch(mm) 0.204 (H) x 0.204 (V)
Panel_Contrast Ratio 1000:1 (typ.)
Panel_Brightness 400 (typ.)
Panel_Viewing Angle -88~88 (H); -88~88 (V)
Active Display Area 261.12 (H) x 163.2 (V)
Display Color 262K/16.2M
Touch(Optional) 4 Wire Resistive Touch
 System Specification
Processor IntelŪ Atom D2550 1.86GHz Dual-core Processor
BIOS AMI 16Mbit Flash
Chipset IntelŪ NM10 Chipset
Memory 1 x SODIMM, Max 4GB DDR3 800/1066
Wireless (Optional) 1x Mini PCI-E base Wireless LAN card with SMA antenna
Lan Controller Dual Broadcom BCM57780 Ethernet
Storage Mini-PCIe SSD
 I/O Connectors
Back Panel I/O Port 2 x RJ-45(10/100/1000 Mbps),
1 x VGA(DB-15), 1 x DC-in Jack(Lockable),
2x USB 2.0,
1x RS232, 1x for RS232/422/485*(Optional),
Line in, Line out, Micro in
WLAN antenna SMA in top(Optional)
 In Fornt Control
Control Button Power On/ Off
Reset
Brightness Up (up to 100%)
Brightness Down (dim to 0%)
Led indicator Power On/ Off
HDD StatusM
 Mechanical and Environment
Dimensions (W x L x H) 310 mm x 215 mm x 52.7mm
Net Weight (kg) (with touch) 2.8
Power Input 9~36V DC in (Phoenix type)
Optional 6-60V DC in, with Ignition On/Off delay
Panel_Operating Temp -25 deg.C to 55 deg.C
Operation Humidity 10% to 95% (non condensing)
Shock* Operating:30g for 18ms, 300m/s2
Vibration* Operating: 1.60/1.96/2.18 g rms for XYZ / 5-500Hz
Certifications CE, FCC ClassB
MIL-STD-810F/ IEC60068-2-27 for Vibration /Shock
EN50155 Compliance
Product Option Items
Sunlight Readable Transflective film enhancement (Optional)
OS Windows XP embedded, Windows7 embedded
Storage Mini-PCIe SSD
Touch / Anti-reflective Glass Infrared Touchscreen, 3mm Anti-reflective Protection Glass
WLAN Mini-PCIe base Wireless LAN card with SMA antenna
