  • Front View
  • Side View
  • Rear View
  • Top View
  • OSD
  • Input/Output
  • Accessories

17" Widescreen Open Frame LCD Monitor w/ VGA, Video inputs (Model WOPW1700A1AV)

WOPW1700A1AV
  • Overview
  • Download
Product discontinues. Contact us at Info@iTechLCD.com for replacement item.
Specification
Model Name WOPW1700A1AV

Screen Size 17"(16:9)

Active Display Area (mm) 372.48 (H) x 223.488 (V)

Pixel Pitch (mm) 0.291 (H) x 0.291 (V)

Display Resolution (pixel) 1280x768

Contrast Ratio 600:1 (typ.)

Display Color 16.7M (8bits/color)

Brightness (CD/m^2) 450 (typ.)

Viewing Angles (CR >=10) -89~89 (H); -89~89 (V)

Synchronization Range_Horizontal / Vertical 31.5~60.0KHz / 60~75Hz

Recommended Resolution 1280x768@60Hz, 75Hz

Signal Connector 15 pin D-sub

Power Source AC 100~240 V,Universal,±10%

Power Consumption 52 W typical, normal operation

Power Management VESA DPMS Compliant

Plug & Play VESA DDC 1/2B

Video Input (optional) S-Video,Composite

DVI Input (optional) Yes

Support Video Signal Type NTSC/PAL

Optional Touch Screen Resistive,SAW

Net Weight (kg) (without touch) 4

Remark: WOPW1700A1 = VGA input only
              WOPW1700A1AV = VGA + Video input


*Due to Panel material's deviation, different panel supplier will set different specific variance range to optical characteristics. The factors of time used, Lamp current, Ambient temperature will influence the optical measurements.
