Wide 7" LCD Monitor IP65 Fully sealed with 5-wired resistive touch USB control (Model: ASW0700WTIP-TR)

Wide 7" LCD Monitor IP65 Fully sealed with 5-wired resistive touch USB control (Model: ASW0700WTIP-TR)
  • Back View
  • Side OSD

Wide 7" LCD Monitor IP65 Fully sealed with 5-wired resistive touch USB control (Model: ASW0700WTIP-TR)

Main Feature

    • 7" Wide LCD Monitor
    • Brightness 500nits
    • Wide Temp: -20°C to 70°C
    • IP65 Fully Sealed
    • 5 Wired Resistive Touch USB Control
Inquiry/Quote Request
ASW0700WTIP-TR
  • Specifications
  • Download
  • Contact Sales
LCD Size 7.0"
Backlight Backlight
Luminance 500 cd/m2
Resolution 800X480
Contrast Ratio 600：1
View Angle 70/70/60/60
Response Time 10/16(Tr/Tf)(ms)
Pixel Size 0.1905x0.1905
Max. Color 262k/16.2M
Touch Panel 5-wired resistive touch panel
Display Area 152.4(H) x 91.44(V)
MTBF 50000 Hrs
Response Time 10ms
Hardness of Surface 3H
Thickness 3mm
Activation Force 30~120g
Durability ≥1 million times
Transmittance ≥78%
DB26 DB26
Operation Temp. -20°C~70°C
Storage Temp. -30°C ~80°C
