Intel® 847E In-Vehicle Computer, 4GB DDR3 Memory included, Internal 2.5" Drive Bay, Mini-PCIe x2 with two SIM card reader, Intel GbE x4, USB x4, COM x2, MIO, Audio, HDMI, DC Power input +9~36Vdc with Ignition, wall mount kit included. (Model: LPC-V5XG-A1)

Overview
Download

Key features

Entry-Level In-Vehicle NVR (SSD suggested)
Removable Bay for Storage
Fanless design with corrugated aluminum
Power ignition management
Wide temperature tolerance
Wall-mountable

Oveview

Built for vehicular settings the LPC-V5XG-A1 has gone through extensive vibration and shock testing, it has been approved under the e13 system as an in-vehicle computer.The LPC-V5XG-A1 has an onboard GPS receiver and 2 Mini-PCIe slots for both WiFi or 3G add-on modules. It allows the LPC-V5XG-A1 to update content as well as offload tracking information along with the captured images to a remote monitoring system in real-time and wirelessly.The system also boasts an abundance of I/O and internal expansion capabilities including 4 USB, 2 COM ports, and DIDO ports.Stand out features of this product include:

Multiple PoE LAN ports to support Transport Surveillance

This mobile NVR with 4 PoE ports (IEEE 802.3af) is suitable for IP Video Surveillance and real-time recording applications.

Design for MIL-STD-810G with Extreme Operating Temperature

This product is ruggedized to support a wider than usual range of temperatures. Outfitted with industrial components (HDD/SSD,CF, Memory) this appliance can thrive in harsh conditions from -30 to 60÷C.

Fanless Design with Corrugated Aluminum

The corrugated aluminum casing allow heat to dissipate off the top of the platform allowing for a fanless design.

Vehicle Ignition Power Management

Detects the ignition on/off status and allow to control delay time by flexible setting via software utility.

Modularized and customizable design

The LPC-V5XG-A1 design features the iTechLCD Proprietary Internal Multi-IO Interface, which carries signals for 2 USB ports, 4 x UART, 4 x Digital I/O, 2 x PCIe, and 1 x SATA 2.0. This allows for customized add-on modules for other features.

Specifications

Platform
CPU	Intel® 847E
Chipset	Intel® HM65
Memory Technology	DDR3 SODIMM x 1
Memory Capacity	8 GB
Storage
IDE storage	1 x CompactFlash (Type II)
SATA storage	2.5” SSD/HDD drive bay x 1 for LVC-5000N4, Internal 2.5” SSD/HDD drive bay x 1 for LVC-5000
I/O
Ethernet controller	Intel® 82583V x 4
Graphic controller	Intel integrated HD graphic engine
Audio controller	Realtek ALC886 HD codec
Default LAN	4 x GbE RJ45
Display output	DVI-D, maximum resolution up to 1920x1200-75Hz VGA, maximum resolution up to 2048x1536-60Hz HDMI, ma
Audio ports	Mic-in and Line-out with 2 watt by terminal block MIO connector
Serial ports	1 x RS-232 and 1 x RS-232/422/485, both with RI/5V/12V
GPS	Ublox NEO-6Q GPS receiver module
Digital I/O	4 x DI and 4 x DO with 5V/12V Level by jumper setting
USB 2.0	4 x Type A
Expansion	Mini-PCIe x 2 (both with SIM card reader)
OS and Certifications
Operating System	Redhat Enterprise 5/Fedora 14. Linux Kernel 2.6.18 or later, Windows XP embedded, Win 7 Pro, Win 8
Certifications	CE Emission, FCC Class A, RoHS, E13
Compliance	Vibration: MIL-STD-810G, Method 514.6, Shock:MIL-STD-810G, Method 516.6
Physical and Environmental
Operating temperature	-5°C to 45°C
Operating temperature (industrial components)	-20°C to 55°C
Dimensions (W x H x D)	273 mm x 65 mm x 188 mm (10.65" x 2.54" x 7.33")
