The VCHH1900Z1 is a Color Active Matrix Liquid Crystal Display with an integral Cold cathode Fluorescent Lamp(CCFL) backlight system. The matrix employs a-Si Thin Film Transistor as the active element. It is a V Series type(1) display operating in the Normally white mode. This TFT-LCD has 19.0 inches diagonally measured active display area with SXGA resolution (1024 vertical by 1280 horizontal pixel array). Each pixel is divided into Red, Green and Blue sub-pixels or dots which are arranged in vertical stripes. Gray scale or the brightness of the sub-pixel color is determined with a 8- bit gray scale signal for each dot, thus, presenting a palette of up to 16.7 M colors. The VCHH1900Z1 has been designed to apply the interface method that enables low power. Flat Link must be used as a LVDS (Low Voltage Differential Signaling) chip. The VCHH1900Z1 is intended to support applications where thin thickness, low power are critical factors and graphic display are important. In combination with the vertical arrangement of the sub-pixels, the VCHH1900Z1 characteristics provide an excellent flat display for office automation products such as Public information, public transportation and outdoor application where sunlight readability is critical.

V Series type means that has a function of transmissive and reflective mode in a body and it is able to use at indoor or outdoor under dark and sunlight at all.


Features:

Active screen size 19.0 inches (48.19cm) diagonal
Outline Dimension 396.0(H) x 324.0(V) x 15.5 (D) mm (Typ.)
Pixel format 1280 horiz. By 1024 vert. Pixels (RGB stripes arrangement)
Color depth LVDS 2port, 8-bit , 16.7M colors
Luminance (white) 420 cd/m2 (Typ.) at center 1 point
Reflectance 2.5 % (Max.)
Power consumption 25.1 Watt at B/L ON, (4.5 Watt at B/L OFF )
Weight 2050 g (Max.)
Display operating mode Sunlight Readable mode, Normally White
Surface treatments UV coating(Max.2%) and Low reflection treatment of the frontpolarizer
At 80Klux: 850nits




Optical Specifications:
Optical characteristics are determined after the unit has been 'ON' and stable for approximately 10 minutes in a dark environment at 25 °C. The values specified are at an approximate distance 500mm from the LCD surface at a viewing angle equal to 0 °.

Parameter
Values
Units
Note
Min.
Typ.
Max.
At Indoor
Brightness
350
420
-
cd/m2
Contrast Ratio
-
760
-
Viewing
angle
(CR ≥ 10)
Left
-
88
-
degree
Right
-
88
-
degree
Top
-
88
-
degree
Bottom
-
88
-
degree
Color
coordinates
White X-axis
Typ -0.05
0.310
Typ. +0.05
-
White Y-axis
0.328
-
At
80Klux
Reflectance
-
-
2.5
%
Brightness
850
cd/m2
Contrast Ratio
-
370
-
-
Response
time
Rise time + Fall time
-
5
10
msec
