17" Ultra Slim Fanless All in One Medical Panel PC (Model: EMPC1700C)

17" Ultra Slim Fanless All in One Medical Panel PC (Model: EMPC1700C)

17" Ultra Slim Fanless All in One Medical Panel PC (Model: EMPC1700C)

EMPC1700C
  • Overview
The Perfect Integration with Medical Cart Application
The ultra-slim type enables easy integration with a mobile medical cart. The 15", 17" and 19" LCD size fits well for medical cart applications. The fanless design enables noise-free and dust-free advantage when being applied to record medical information next to patients. The wireless network connection allows real-time patient data checking and processing in the e-medical environment. The preinstalled bluetooth module provides perfect connection to a wide range of medical peripherals, such as barcode readers and manometers. The user-friendly touch screen design makes medical data entry more convenient.
 Features
15", 17", 19" medical panel PC for clinical review applications
Fanless design with built-in 1.0 GHz Intel® Celeron® M processor
Ultra-slim type for easy integration
User-friendly touch screen
Preinstalled bluetooth module for powerful connectivity
Network advantage for reliable data transmission
POC-4/A Series IO


Ultra-Slim TypeUltra-Slim Type for Easy Integration
The EMPC-C series are designed with an ultra-slim outlook and a thickness of 67 mm only. The slim type design makes the EMPC-C Series easier to be mounted on any medical device, such as CT, CR and medical cart, being a platform to process medical information.

Fanless Design for Noise-free Applications
FanlessThe EMPC-C series are fanless all-in-one panel PC with a preinstalled Intel® Celeron® M CPU. The fanless design provides quiet operation when being used as a medical information terminal beside patients.

Bluetooth Module for Perfect Connections
Bluetooth Module for Perfect ConnectionsThe preinstalled Medical Display Pro bluetooth module provides a wireless connection to a wide range of medical peripheral devices. High speed data transmission through the USB 2.0 interface is perfect for processing patient data.

Reliable Network Connection Advantage
Reliable Network Connection AdvantageThe EMPC-C series have two Gigabit Ethernet LAN connectors and Wireless 802.11b/g network connections, increasing redundancy and ensuring reliable network for real-time medical record processing.

DC Power Input for Mobile Medical Application
The 12V DC power input with external power adapter enables easy integration with mobile medical carts.


Reliable Touch Screen DesignReliable Touch Screen Design
The EMPC-C series are equipped with reliable 5-wire resistive type touch screen. The touch screen makes medical order entry much easier when being used as a recording terminal.

IP 64 Front Panel for Best Reliability
The EMPC-C series are designed with IP 64 dustproof and waterproof front panel, enabling implementation in humid area of the hospital. The paint-coating-free front bezel can be cleaned easily with disinfectant without harming the panel itself.

       Specifications
Model EMPC1500C EMPC1700C EMPC1900C Model EMPC1500C EMPC1700C EMPC1900C
LCD size (inch) 15" 17" 19" Touch screen Resistive 5-wire (RS-232 interface)
CPU 1.0 GHz Intel® Celeron® M with 512 KB L2 cache on-board
(Celeron® M 373)
Wireless
(Mini PCIe interface)
802.11 b/g
RAM 2 x 1.0 GB (max.) DDR2 SO-DIMM
(system max. 2.0 GB)
Bluetooth
(USB interface)
Yes
Chipset
Intel® 910GMLE + ICH6M
Speakers
2 x 1.5W AMP
Resolution
1024 x 768
1280 x 1024 1280 x 1024 IP level
IP64 on front panel
Drive Bay
1 x 2.5 SATA HDD
1 x IDE CF card
OSD Function
Five buttons (LCD On/off, Light +,-, Audio +,-)
Power In
DC 12V input
LED Function One front panel power on/off LED
Power Adapter Medical Grade, AC 100V~240V input to DC 12V output Safety & EMI UL60601-1, EN60601-1, CCC, CE(EN60601-1-2), FCC Parts 18
I/O Ports 4 x USB 2.0
2 x RS-232
2 x Gigabit Ethernet (GbE)
1 x VGA
1 x Audio, Line-out
1 x SATA
1 x Power inlet connector
Operation Temperature
0°C ~ 40°C
Dimensions
(W x H x D)
(mm)
394 x 309 x 61 428 x 350 x 65 470 x 383 x 67
Net Weight (kg) 3.7 5.4 6.2

       Ordering information
Part No. Description
EMPC1500C 15" fan-less medical panel PC, with 1.0 GHz Intel® Celeron® M with 512 KB L2 cache on-board CPU (Celeron® M 373), 1GB DDR2 SO-DIMM RAM, 80GB SATA HDD, wireless 802.11 b/g, Bluetooth, touch screen and AC to DC power adapter, RoHS
EMPC1700C 17" fan-less Medical panel PC, with 1.0 GHz Intel® Celeron® M with 512 KB L2 cache on-board CPU (Celeron® M 373), 1GB DDR2 SO-DIMM RAM, 80GB SATA HDD, wireless 802.11 b/g, Bluetooth, touch screen and AC to DC power adapter, RoHS
EMPC1900C 19" fan-less medical panel PC, with 1.0 GHz Intel® Celeron® M with 512 KB L2 cache on-board CPU (Celeron® M 373), 1GB DDR2 SO-DIMM RAM, 80GB SATA HDD, wireless 802.11 b/g, Bluetooth, touch screen and AC to DC power adapter, RoHS

       Optional Mounting Kit
Wall Mount Kit AFLWK-19
ARM ARM-11-RS, ARM-31-RS
STAND STAND-A19, STAND-B19
