Shallow, Sliding Rackmount Monitor Kit, 4Post (Model: RMK2U4P100-S)

Shallow, Sliding Rackmount Monitor Kit, 4Post (Model: RMK2U4P100-S)

Shallow, Sliding Rackmount Monitor Kit, 4Post (Model: RMK2U4P100-S)

  • Overview
  • Download
The Rackmount Monitor Kit allows you to use a standard Flat Panel Monitor and install it into a Rack and save hundreds of dollars over the cost of other similar products. The kit supports Flat Panel Monitors with 75 mm or 100 mm hole patterns. The Rackmount Monitor Kit can be installed in Racks with an installation depth from 16 - 23" (406 - 584 mm). The articulated, cable management arm is sold separately.

Use your monitor or select our 17", 19" LCD

  • Supports 15" - 19" LCD with a VESA mount
  • Compatible with any KVM switch
  • Articulated cable management arm sold separately

Fits any 4Post racks

  • Square, round holes
  • Adjustable mounting depth of 16 - 23" (406 - 584 mm)
  • Only requires 2U of rack space


Interface VGA
Rack Units 2U
Rack Type 4Post
Included Hardware 10-32 and 12-24 Screws
Cage nuts provided for square hole racks
Mounting Depth Range 16 - 23" (406 - 584 mm)
Rail Type 28" Travel (394 mm)
Ball Bearing Slides
Overall Installation Depth 23" Minimum
Cable Management Articulated Cable Management Arm, P/N 137-2282, sold separately
VESA Mount 100 mm or 75 mm VESA hole patterns (required)
Most LCD display have a four hole VESA mounting holes on the back
The VESA holes may be hidden by the display stand
Monitor Width LCD display width: 17.5" (444.5 mm) maximum
15" 17" or 19" (381 mm, 432 mm or 483 mm) LCD display typically fit
Monitor Thickness LCD display thickness: 2.75" (70 mm) maximum
Exceeding this thickness will require more than 2U of rackmount space
Monitor Specs 17” (432 mm) Monitor Specs
Monitor is Dell E170S (optional)
1280x1024 Pixels @ 60Hz Max. Resolution
TFT Active Matrix
250 cd/m Brightness
800:1 Image Contrast Ratio

19” (483 mm) Monitor Specs
Dell E197FP (optional)
1280x1024 Pixels @ 75Hz Max. Resolution
TFT Active Matrix
300 cd/m Brightness
500:1 Image Contrast Ratio
Assembly Notes Fully Assembled except for optional monitor
Cable routing required
