Server Cabinet Rack Enclosures 42U, 39.4" Deep (1000mm) (Model: W6042) |
 |
|
| From day to day operation, W-Series also facilitates IT professionals to make maintenance a breeze. Easy system installation and upgrade with tight cable management and central power distribution control can reduce service time and money for more important things in life. |
| The data center administrator today face challenge of thermal management from a high density and high power server system. W-Series cabinet designed with excellent air ventilation and filtration that address cooling requirement as well as prevent dust entering valuable hardware equipment. |
| The W-Series professional rackmount cabinet is compatible across different rackmount standard. It can fit rack from vendors such as IBM, HP, Dell, and
rackmount chassis. Universal compatibility ensures high compatibility for upgrade and system expansion over time. |
| Cooling: |
Because of the high performance and high power that was drawn by the system, each generates significant heats that add up to a major cause of system failure. The thermal cooling design of W-Series provide superior cooling to ensure system operation and temperature control of the environment. |
| Compact: |
More system per rack and high demand of system availability and serviceability have made server room and data center look for cabinet that enable space saving and more manageability. W-Series provide the solution for small, medium, and large cabinets. |
| Power: |
Power connection can be a hectic task with large cabinets. Self-implement of PDU can be located anywhere in the cabinet to better manage and monitor the power inputs. W-Series provide variety of PDUs includes 110V, 220V, and DC inputs with European and US standards.
|
| cabling: |
The headache created by the network cabling brings nightmare to every IT professionals. They spent hours to sort out the mess instead of focus on more important task. W-Series efficiently use available space to route cable and cords to better manage cabling and increase air flow of over all system. |
| Security: |
The server room and data center holds expensive equipment and critical company data, security have become an extreme important issue in keeping the entire valuable asset safe. Cabinet level security locks on both front and rear door to protect unauthorized access to server and data. |
Custom: |
i-Tech provide full package solution from rackmount, power supply to cabinet. The customized silk screen and accessories enable company to further enhance product image and brand name awareness. Our goal is to support business achieve success. |
| Bottom Line: |
i-Tech make customer needs our top priority because our success is based on yours.
i-Tech provide cost effective and customization solution that enhance performance and product image of your company. |
| Specification: |
| Model No. |
W6842 |
| Format |
19" Rackmount - 42U |
Dimensions
(WxH[w/Castor]xD) mm |
23.62" x 78.74" [81.5] x 39.37"
600 x 2000 [2070]x 1000 |
| Basic Equipment |
Variable 19" Profiles at Front and Backside
Vented Lockable Doors at Front and Backside
Lockable Side Panels w/ Quick Lockers |
| Cooler |
Four Installed 120mm 220V Low Noise Fans Included
Dust Filter System on Top of Cabinet |
| Color |
RAL7032(Pebble-Grey) / RAL9011(Black)
Special Color on Request - Minimum Order 10 pcs |
| Safety |
TUEV |
| EMI Noise Filter |
CE |
| Racking Specifications |
| Conformance |
ANSI/ELA, RS-310-D, IEC297-2 |
| Rack Height |
42U |
| Mounting Rail Opening |
20 inches |
Mounting Hole
Center-to-Center |
19 inches |
| Load Capacity |
1760 lbs (800 kgs) |
| Material |
| Frame |
Aluminum |
| Base |
SPCC Cold Rolled Steel t1.2 |
| Mounting Rails |
SPCC Cold Rolled Steel t2.0 |
| Top Panel |
SPCC Cold Rolled Steel t1.2 |
| Side Panels |
SPCC Cold Rolled Steel t1.2 |
| Doors |
SPCC Cold Rolled Steel t1.5 |
