19” Industrial Rugged Fanless IP65 Resistive Touch Stainless Steel Panel PC (Model: iCHPC1900IP-A)

19” Industrial Rugged Fanless IP65 Resistive Touch Stainless Steel Panel PC (Model: iCHPC1900IP-A)
  • Front View
  • Back View
  • Bottom View

19” Industrial Rugged Fanless IP65 Resistive Touch Stainless Steel Panel PC (Model: iCHPC1900IP-A)

rugged-industrial-panel-pc-ichpc1900ip-a
  • Overview
  • Download
Product discontinues. Call us at 888-483-2418 for replacement item.

iCHPC1900IP-A is the ultimate industrial fanless rugged IP65 solution. It features Intel® Atom™ Processor N270, 1.6 GHz with a 19” TFT LCD XGA Resistive Touch screen. It provides the best high definition video performance to support multimedia applications. It also features 2x 2.0 ports, 1x LAN, 2.5” SATA hard drive. it supports Windows XP pro and Windows Embedded on a hard drive, solid state, hard drive, or a Compact flash ™ module. ICHPC1900IP-A can be broadly implemented and is suitable in several markets such as, industrial automation, food processing factories, POS, and kiosks.

FEATURES:

- Intel® Atom™ Processor N270, 1.6GHz
- 19” TFT Resistive Touch XGA Screen
- 2 x COM Ports for Transaction Terminal Applications
- 1 x 10/100/1000 Gigabit LAN
- 2 x USB 2.0 Ports
- Stainless Steel, IP65
- Fanless and Dustproof


SYSTEM
CPU Intel® Atom™ Processor N270, 1.6GHz
Chipset Intel ® 945GSE + ICH7M + N270
Memory 1 x DDR2 DIMM, Default 2 GB
Mounting VESA Compatible 75x75 (mm)
HDD 2.5” 160 GB
Operating Temp. 0°C ~ 60°C / 32°F~ 140°F
Power Supply AC-DC AC 100-240V 80W
Certificate FCC, CE, UL, CUL, TUV
I/O 2 x COM ports, 2 x USB Ports, 1x Lan port 1 KB/Mouse port , 1 DC12V-in port

DISPLAY
Chipset Integrated in Intel® 945GSE GMCH
Memory Max. Up To 128MB Frame Buffer Sharing System
Resolution 1280x1024 Pixels (Native Resolution)
Contrast Ratio 1000:1 (Typical)
Brightness 300 (cd/m2)
Viewing Angle Horizontal: 85°/85°, Vertical: 80°/80°
Touch Resistive Touch screen
Housing Stainless steel Housing

PACKING LIST
AC Adapter, Driver CD

OPTIONAL
Solid State Replace 2 .5” SSD or Compactflash™
OS Windows® XP Home, XP Embedded, XP Pro
