Rugged industrial monitors/Panel Mount LCD Monitor 15" w/ video input (iNAP-1500AV)

Rugged industrial monitors/Panel Mount LCD Monitor 15" w/ S-Video, & Composite Video input & optional touch screen (Model iNAP-1500AV)

Product discontinues. Contact us at Info@iTechLCD.com to find out more information.

Features

15" VGA TFT LCD support 1024 x 768 pixels
450cd/m2 industrial brightness
OSD control keys to optimize the display
Different models fit for various application
Rugged construction
6mm aluminum front cover
Front IP protection
Modulariezed design
Low power consumption
Optional with touchscreen and DC power input
Video input (S-video & Compsite)
Wide-ranges Mounting kits (VESA mount, Wall mount, Panel mount, OEM mounting design...)

Specification
LCD
LCD Type	Samsung Grade A industrial TFT LCD Panel
Display Size	15 inch diagonal
Resolution	1024 x 768, VGA
Display Color	16.2M color
Brightness	450 cd/m2
Contrast Ratio	400 : 1 (Typical)
Pixel pitch	0.297 x 0.297 mm
Viewing Angle	70 / 70 / 60 / 65 (L / R / U / D)
OSD Control	Brightness, Contrast, Phase & Clock, Color, H & V position, Auto-tune & Recall
Backlight lifetime	50,000 hrs
Signal Input
Horizontal Input Video Signal	Analog RGB
Video Level	Analog: 0.7Vp-p
Sync Type	Separate H/V, Composite H/V
Input Connector	D-Sub 15 Pin VGA analog
Video Input
Video Input	S-Video and Composite
Input Connectors	RCA, S-video
Touch Screen (Optonal)
Type	5-Wire Resistive	Surface Accoustic Wave
Thichness	2.2mm	3mm
Light Transmission	87%	90%
Controller	Serial / USB	Serial / USB
Durability	35 million	50 million
OS Support	Windows XP, 2000, NT, 98, DOS and Linux
External Power Adapter
Power Input	110 or 220 VAC at 50 or 60 Hz via AC adapter (12V, 8.3A)
Optional DC Power	12V, 24V or 48V DC input
Mechanical
Material	6mm Aluminum (Front panel) 1.2mm Steel (Rear case)
Finish	Powder Coating
Color	Front Panel : Black Back : Dark Grey (RAL7037)
Dimension	390.4 x 55.3 x 300 mm (WxDxH)
Weight	3.5 kg
Environmental
Temperature	0 to 50 Degree Celsius (Operation) -20 to 60 Degree Celsius (Storage)
Relative Humidity	70%, non condens
Shock	49G peak acceleration (11ms, half since wave)
Vibration	58~500Hz/ 0.98G (11min/ cycle)
Package Information
Carton Box	555 x 90 x 470 mm (WxDxH)
Weight	5.5 kg
