Rack Mount, 15" LCD monitor, 1024x768, LED 250 nits, VGA input with IR Touch (Model: ERM1500-IR)

Rack Mount, 15" LCD monitor, 1024x768, LED 250 nits, VGA input with IR Touch (Model: ERM1500-IR)

Rack Mount, 15" LCD monitor, 1024x768, LED 250 nits, VGA input with IR Touch (Model: ERM1500-IR)

ERM1500-IR
  • Overview
  • Download

Features:

  • Modularize mechanical design provides flexible product confguration and easy maintenance
  • Optional build-in touch screen for interactive application
  • Available with auto-brightness sensor offers application in day and night
  • VGA connector with optional AV,SV,AV-Looping
  • Complete custom design/solution for OEM customers

Specifications:

Panel         Cell Type / Glass Surface TFT LCD / Black Anti-Glare, low refection coating
Aspect Ratio / Size 4 : 3 / 15" viewable diagonal area
Active Area / Pixel Pitch 304.13(H) x 228.10(V) mm / 0.297(H) x 0.297(V) mm
Native Resolution / Colors 1024(H) x 768(V) / 16.2 M
Brightness / Contrast 250 cd/m2 (typ) / 700 : 1
Response Time ≤ 35 ms
Viewing Angle (typical) H. 140o (- 70o ~ + 70o) , V. 120o(- 60o ~ + 60o)
Light Source LED backlight, Long life, 35,000 hrs (typ)
Input Sources     PC System Signal Analog RGB (0.7/1.0 Vp-p, 75 ohms)
  Sync Separate Sync, Composite Sync, Sync On Green
  Frequency Fh : 30 - 82Khz , Fv : 50 -75Hz
Audio System 2W speaker x 2
Input Terminals 1 x VGA (15 Pin Female D-Sub) , 1 x PC Audio (Stereo Headphone Jack) , 1 x DC Power Plug
Convenient Features   Auto Calibration , Back Light Adjustment , Plug&Play (VESA DDC/CI, DDC 2B)
OSD Multi-Languages , Wall Mount Ready (VESA Dimension - please refer to Drawing)
Power Internal power supply with universal / Auto-Sensing, AC90 to 260V, 50/60 Hz
Power Consumption Operation / Power Saving 20 watt , < 2 watt (Support DPMS)
Operating Condition Temperature / Humidity 0oC ~ 50oC (32oF ~ 122oF) , 10% ~ 90% (no condensation)
Storage Condition Temperature / Humidity - 20oC ~ 60oC (- 4oF ~ 140oF) , 10% ~ 90% (no condensation)
Certification   FCC , CE
Dimensions   Physical Please refer to Drawing
Carton W x H x D = TBD
Weight N.W. / G.W. 4 Kgs / 5 Kgs
Container Loaded 20ft / 40ft / 40ft HQ TBD (Sets , By pallet)

Options Touch Video / TV Enhanced Panel Others
Resistive (With glass) SV + AV Panel with LED backlight Digital Signage(Stand alone)
Capacitive

SV + AV + AV_Looping

High brightness panel Networking Digital Signage
SAW SV + AV + TV Wide Temperature Motion Sensor
    Sun Light Readable Light Sensor
      Auto-Dimming
