15" LED TFT LCD 800x600 w/ 15" G+G Projected Capacitive Touch Screen w/ Panel Module Metal Chassis & Aluminum Front Bezel Gen7 Core i3 w/ Locking AC-DC Power Adapter w/ Intel(r) Core(tm) i3-7100U(2.4GHz) w/o Ram w/o Storage. (Model: QPC1500-i3)

15" LED TFT LCD 800x600 w/ 15" G+G Projected Capacitive Touch Screen w/ Panel Module Metal Chassis & Aluminum Front Bezel Gen7 Core i3 w/ Locking AC-DC Power Adapter w/ Intel(r) Core(tm) i3-7100U(2.4GHz) w/o Ram w/o Storage. (Model: QPC1500-i3)

15" LED TFT LCD 800x600 w/ 15" G+G Projected Capacitive Touch Screen w/ Panel Module Metal Chassis & Aluminum Front Bezel Gen7 Core i3 w/ Locking AC-DC Power Adapter w/ Intel(r) Core(tm) i3-7100U(2.4GHz) w/o Ram w/o Storage. (Model: QPC1500-i3)

Main Feature

  • Powered by Gen7 Intel® Core™ U-series i7 / i5 / i3 processors, up to 3.4GHz for tougher performance requirement
  • 15" G grade LED LCD panel for long life cycle and your tough working environments
  • Modularized Design for different application needs and minimal system down time during maintenance
  • Solid and rugged System Construction withstands punishments from all environments
  • True Flat multi Touch with front side IP65 certification
  • Supports USB 3.0, Supports Dual Gbe Ethernet port
  • Wide Range Power Input (+9 ~ +24VDC)
  • 2 Different mounting methods designed in for ultimate application flexibility
  • Optional Wireless Module or mSATA SSD Module
QPC1500-i3
  • Specifications
  • Download
  • Contact Sales
System
Processor Intel® Core™ 7th Generation U-series i3
System Memory 2x DDR-4 2133 SO-DIMM, Max 32GB (Non-ECC)
Storage 2.5" SATA HDD or mSATA SSD
I/O Serial port *4 (RS232/422/485 *1, RS232*3)
USB *7 (USB 3.0*4, USB 2.0*3)
Ethernet, PCI-e Gbe LAN *2, RJ-45
HDMI 1.4a *1
Displayport *1
Line in *1, Line out *1, Phone Jack
Expansion Interface One Mini PCI Express Socket

Touch screen Projected Capacitive Touch
OS Support Microsoft Windows 7, 8, 8.1, 10, POSReady7, Linux Kernel 3.19
Power Requirement DC Jack, +9V~+24V Wide Range Input

Display
LCD 15" TFT XVGA
Resolution 1024*768, 16.2M Colors
Luminance (cd/m2) 250
Viewing Angle 160°/140°
Backlight Lifetime 50,000 hrs/ LED

Mechanical
Construction Heavy-duty steel chassis(Black Color), Aluminum Front
Operation Temp. 32°F ~ 140°F (0°C ~ 60°C) with Ambient Air
Storage Temp. -22°F ~ 175°F (-30°C ~ 80°C)
Relative Humidity 10-90% @40°C, Non-condensing
Vibration 5~17Hz, 0.1" double amplitude peak to peak, 1.5G acceleration peak to peak
Shock 10G acceleration peak to peak (11ms)
Rating IP 65 compliant front bezel
Qualification Formal certification CE / FCC Class B
Mounting Panel / VESA 75 mount / Wall
Dimension 355mm*93mm*290mm (L*W*H)
Packing Dimension TBD
Weight (net) TBD

Optional Order
Memory SODIMM DDR4-2133 4GB/ 8GB/ 16GB
Storage 2.5" SATA HDD 320GB, mSATA SSD 16GB-128GB
OS Microsoft Windows 7/8/8.1/10, POSReady7
Wifi Lan RTL8188CUS-BC8-WB
