Open frame, 20.1" LCD monitor, 800 x 600, 450 nits w/ Capacitive Touch with USB (Model: EOP2000HB-TC)

Open frame, 20.1" LCD monitor, 800 x 600, 450 nits w/ Capacitive Touch with USB (Model: EOP2000HB-TC)
  • Front View
  • Front View
  • Front View
  • Front View
  • Side View
  • Back View
  • Back View
  • Back View
  • Accessories View

Open frame, 20.1" LCD monitor, 800 x 600, 450 nits w/ Capacitive Touch with USB (Model: EOP2000HB-TC)

EOP2000HB-TC
  • Overview
  • Download
Product discontinues. Call us at 888-483-2418 for replacement item.

Features:

  • Modularize mechanical design provides flexible product configuration and easy maintenance
  • Optional ultra high brightness panel
  • VGA connector with optional AV.SV.AV-Looping
  • Available with auto-brightness sensor offers application in day and night
  • Complete custom design/solution for OEM customers

Specifications:


Panel Cell Type / Glass Surface TFT LCD / Black Anti-Glare, low reflection coating
Aspect Ratio / Size 4:3/ 20.1" viewable diagonal area
Active Area / Pixel Pitch 408.0(H) x 306.0(V) mm / 0.51(H) x 0.51 (V) mm
Native Resolution / Colors 800(H) x 600(V) / 16.7 Million
Brightness / Contrast 450 cd/m2 (typ) / 700 : 1
Response Time ^ 16 ms
Viewing Angle (typical) H. 160° (- 80° ~ + 80°) , V. 140°(- 60° ~ + 80°)
Light Source CCFL , Long life, 50,000 hrs (typ)
Input Sources PC System Signal Analog RGB (0.7/1.0 Vp.p, 75 ohms)
Sync Separate Sync, Composite Sync, Sync On Green
Frequency Fh: 30 - 82Khz , Fv: 50 -75Hz
Audio System 2W Amplifier
Input Terminals 1 x VGA (15 Pin Female D-Sub), 1 x PC Audio (Stereo Headphone Jack), 1 x AC Outlet
Convenient Features Auto Calibration , Back Light Adjustment, Plug&Play (VESA DDC/CI, DDC 2B)
OSD Multi-Languages , Wall Mount Ready (VESA 100 x 100 mm)
Power Internal power supply with universal / Auto-Sensing, AC 90 to 260V, 50 / 60 Hz
Power Consumption Operation / Power Saving 43 watt, < 5 watt (Support DPMS)
Operating Condition Temperature / Humidity 0°C ~ 50°C (32°F ~ 122°F), 10% ~ 90% (no condensation)
Storage Condition Temperature / Humidity - 20°C ~ 60°C (- 4°F ~ 140°F), 10% ~ 90% (no condensation)
Certification   FCC,CE
Dimensions Physical With Flanges(W x H x D): 462.0 x 384.0 x 70.0
Without Flanges(W x H x D): 462.0 x 358.0 x 70.0 (mm)
Carton W x H x D = 560 x 463 x 205 mm
Weight N.W. / G.W. 6.7 Kgs / 7.7 Kgs
Container Loaded 20ft / 40ft / 40ft HQ TBD (Sets , By pallet)

Options Touch Video / TV Enhanced Panel Others
Resistive (With glass) SV + AV Panel with LED backlight Digital Signage(Stand alone)
Capacitive SV + AV + AV Looping High brightness panel Networking Digital Signage
SAW SV + AV + TV Wide Temperature Motion Sensor
Infrared   Sun Light Readable Light Sensor
      Auto-Dimming
