Medical Grade 58" Quad FHD 8MP LED Monitor with AR Glass 3840x2160, 700nits, 2DP+DVI (Model: GMM5800)

Medical Grade 58" Quad FHD 8MP LED Monitor with AR Glass 3840x2160, 700nits, 2DP+DVI (Model: GMM5800)

Medical Grade 58" Quad FHD 8MP LED Monitor with AR Glass 3840x2160, 700nits, 2DP+DVI (Model: GMM5800)

GMM5800
  • Overview
  • Download

Overview

iTechLCD's NEW LIGHTWEIGHT 8MP LED monitor is the ideal choice for reproduction of multiple images concurrently in the operating room. This vivid, precise, display delivers consistently uniform images that can be scaled and maneuvered to highlight the most immediately vital picture and minimize the less important. With a native resolution of 3840x2160, it is unsurpassed in clarity and our Automatic Luminance Stabilization system assures that it will remain so. The combination of QFHD monitor and MDM / KVM video processors deliver the stability and reliability of a custom engineered hardware solution suitable for Medical Applications such as Hybrid Operating Room, EP Labs, Cath Lab, and for any process where monitoring must be constant where control must be precise.


Specifications

LCD Panel Type TFT color, active matrix
Native Resolution 3840x2160
Active Screen Size (inch) 58 inches diagonal
Display Area (mm) 1270.08 (H)x 721.44 (V) mm
Pixel Pitch (mm) 0.334 mm x 0.334 mm
Viewing Angel (degree) 176 degrees (H) /176 degrees (V)
Response Time (ms) 8.5 ms gray-gray (average)
Visual Characteristics Brightness (nits) 700 cd/m2 (Max)
Contrast Ratio 4000:1 (Max)
Display Colors (bits) 10 bit Colors DP; 8 bit color DVI
I/O Interface Input Terminal (DVI-D) x 2 dual Link and 2 x Display Port (Selectable)
External DC Power 5VDCx2
Service Interface RS-232D-Sub 9-pin mini xl
USB HUB USB Rev. 2.0, upstream x 1, downstream x 2
Features Gamma Preset 2.0,2.2, DICOM, User
Color Temperature Preset 5400K, 6500K, 7500K, 9300K, User; RGB Gain; RGB Offset
Power Requirements Power Supply AC100-240V,50~60Hz
Power Consumption 310W (max); 11W (power saving)
Physical Characteristics Dimensions (WxHxD) Unpacked with stand: 1345 x 866.4 x 299.2 (mm)
Unpacked without stand: 1345 x 800.8 x 138.7 (mm)
Weight Unpacked without Glass: 45 Kg/ 99 Lb
Unpacked with Acrylic Glass: 48 Kg (IPX 1 Front Bezel
VESA Mounting VESA 600x400mm
Environmental Operating Temperature +5°C to + 35°C (32°F to 95°F)
Operating Humidity 30% to 75%
Others Certifications and Compliances cTUVus (UL 60601-1, CAN/CSA C22.2 No. 60601-1), CB (IEC 60601-1), TUV/RH (EN 60601 -1), FCC, CE, RoHS, WEEE
Supplied Accessories AC power cord, DVI-D to DVI-D cable, warranty card
