GMM2400
  • Overview
  • Download

Overview

iTechLCD latest 24" medical display not only conforms to Medical-grade UL/CE-60601-1 and other major international certifications for safety and quality assurance but also provides the kind of crisp, clear 1920x1200 resolution that can only be achieved using IPS liquid crystal technology. The 24" display is the precise tool the practitioner needs to make the sharpest analysis and the most reliable diagnosis, or to produce the truest image of an operation in real time.


Specifications

ID Type True Flat (White)
Panel spec Type IPS
Resolution 1920(H)x1200(V)
Active Screen Size (inch) 24
Display Area (mm) 518.4(H)x324(V)
Pixel Pitch (mm) 0.27(H)x0.27(V)
Viewing Angel (degree) 178(H)/178(V)
Response Time (ms) 6 (typ.)
Brightness (nits) 350(typ.)
Contrast Ratio 1000:1(typ.)
Display Colors (bits) 8+FRC
I/O Interface DVI Yes(in x1)
HDMI Yes(in x1)
DP Yes(in x1)
VGA Yes(in x1)
Composite (BNC)(In)(Out) Yes(in x1 out x1)
S-Video(4pins Mini-Din)(In)(Out) Yes(in x1 out x1)
RGBS/YPbPr(BNC)(In)(Out) Yes(in x5 out x3)
SDI/HD/3G-SDI(BNC)(In)(Out) Yes(in x1 out x1)
Serial Remote RS232(D-sub 9pin)
Features Color Temp. Adjust Warm-5400K/Cool-9300K/Neutral-6500K/User
Gamma Selection Monochrome/DICOM/Calibrate/1.8/2.0/2.2/2.4
OSD Languages English/Spanish/French/German/Italian/S.Chinese /Japan
PIP PAP PIP/PAP
Scaling OverScan Full/Auto/16:10/16:9/Width Fit/4:3/1:1/Hight Fit
User Color Adjust R Gain/G Gain/B Gain
HDMI Video Format Auto/YCbCr 4:4:4/YCbCr 4:2:2/ RGB
Gamma LUT Table (bits) 10
Power Requirements Power Supply DC 24V
Power Consumption (W) <80
Physical Characteristics Protection Shield Yes (AR Glass)
Tilt Range(degree) -5~+25
Dimensions(W×H×D) (mm) 390 x 584.4 x 109.63
Weight (Kg) 8.5
IPxx Front IP65
Mounting (mm) 100x100 / 200x100
Operating Temperature 10~40
Certifications and Compliances cTUVus(ANSI/AAMI ES 60601-1, CAN/CSA C22.2No. 60601-1), CB (60950/60601), CE,FCC ClassB part 15 CCC,VCCI, BSMI
