32" Large-Screen NEC LCD Display (Model: V321-2)

32" Large-Screen NEC LCD Display (Model: V321-2)

32" Large-Screen NEC LCD Display (Model: V321-2)

V321-2
  • Overview
  • Download
Go digital with your messaging using the 32" NEC V321-2, an entry-grade, large-screen LCD display that provides a cost-conscious solution for digital signage applications. This model features rear-mounted speakers, a public display-grade panel that protects against permanent image retention and a full selection of inputs, which allows you to connect to a wide range of peripheral devices. The high-performance panel and an abundance of advanced technologies that promote extended use, along with an adaptable cabinet design, make the V321 ideal for retail and restaurant markets, as well as indoor venues, training facilities and corporate boardrooms.

Features:

  • 15W rear-mounted speakers provide sufficient volume for large rooms
  • Commercial-grade extends the display's use for various applications
  • Wide range of inputs, including DVI, VGA, shared 5-BNC, S-Video and HDMI
  • TileMatrixTM allows you to create video walls up to 5x5
  • High brightness (450 cd/m2 brightness) and contrast ratio (3000:1) help create eye-catching images and crisp, easy-to-read text
  • Text ticker creates a dedicated portion of the screen for applications such as news updates and emergency warnings
  • Protective-glass and touch-panel-ready design provides opportunities for module protection and interactivity
  • Landscape and portrait orientations allow for flexible content placement, maximizing audience awareness

Specifications:

Display
Viewable Image Size 32"
Pixel Pitch 0.51mm
Pixels Per Inch 50
Brightness 450 cd/m2
Contrast Ratio 3000:1
Viewing Angle 178º Vert., 178º Hor. (89U/89D/89L/89R) @ CR>10
Response Time 8 ms (gray to gray)
Synchronization Range
Horizontal 31.5-91.1 KHz (Analog) / 31.5-91.1 KHz (Digital)
Vertical 50-85 Hz Analog/Digital
Input Signal
Video ANALOG RGB 0.7 Vp-p/75 Ohms; Separate sync: TTL Level; (Positive/Negative)
Sync Separate: TTL Level (Pos/Neg)
Input Connectors HDMI, DVI-D, Analog 15-pin D-sub, 5 BNC (RGB/HV, DVD/HD or Composite Video), BNC Composite Video, S-Video
Native Resolution 1366 x 768
Power Consumption
On 75W
Power Savings Mode <1W
Dimensions (WxHxD)
Net (with stand) 31.1 x 21.14 x 9.68 / 789 x 537 x 246mm
Net (without stand) 31.1 x 18.8 x 5.2 in. / 789 x 476.3 x 133mm
Net Weight (with stand) 33.5 lbs / 15.2kg
Net Weight (without stand) 31.5 lbs. / 14.3 kg
VESA Hole Configuration Specifications 400 x 200mm (12 hole)
Environmental Conditions
Operating Temperature 5-40º C / 41-104º F
Operating Humidity 20-80%
Operating Altitude 0-3000m
Storage Temperature -20-60º C / -4-140º F
Storage Humidity 10-90%
Storage Altitude 12,000m / 39,370 ft.
Warranty 3 years parts and labor, including backlight
Additional Features Standard bezel, sealed panel design, Ethernet Control and Communication, TileMatrix (5x5), TileComp, programmable lookup tables, Plug and Play (DDC/CI, DDC2B), PIP/POP/side-by side picture, 6-axis color adjustment, 10-bit gamma, multi-level programmable zoom, scheduler (w/ RTC), sharpness/softness, off-timer (countdown), screen saver, vacation switch, AutoBright (signal input), Windows Vista-certified, portrait-capable, touch- and protective screen-ready, color temperature adjustment (2600-10,000K)
