Rugged Completely Sealed IP66 Stainless Steel Chassis Mount 17"LCD monitor, 1280 x 1024, 1000 nits, Intel® Atom D2550 Processor, 5 Wire Resistive Touch Screen and USB Controller (Model: SCH1700HB-SIP-PC-TR)

Rugged Completely Sealed IP66/NEMA4X Stainless Steel Chassis/Surface Mount Water/Dust proof 17" High Brightness Panel PC LCD monitor LED backlight, 1280 x 1024, 1000 nits, with 2mm AR glass and DVI input with Intel® Atom D2550 Processor and NM10 onboard, 5 Wire Resistive Touch Screen and USB Controller (Model: SCH1700HB-SIP-PC-TR)

Rugged Completely Sealed IP66/NEMA4X Stainless Steel Chassis/Surface Mount Water/Dust proof 17" High Brightness Panel PC LCD monitor LED backlight, 1280 x 1024, 1000 nits, with 2mm AR glass and DVI input with Intel® Atom D2550 Processor and NM10 onboard, 5 Wire Resistive Touch Screen and USB Controller (Model: SCH1700HB-SIP-PC-TR)

SCH1700HB-SIP-PC-TR
  • Overview
  • Download

Features:

• 17" Bright Active Matrix TFT Display, 1000 Nits (cd/m²)
• 1280 x 1024 High Resolution
• Built-in Intel Atom D2550 Dual Core 1.86Ghz CPU, Fanless Design, 32GB Wide temp SSD and 4GB Memory (DVI x 1 + RS232 x 1 + USB x 2 + POWER x 1 + LAN x 1)
• NEMA 4X (IP66) 304 Stainless Steel Gasket Sealed Enclosure
• DVI-D only for external video input
• Included all water proof connectors and 6ft long water proof cables.
• LED backlight Energy Efficient, Low Power Consumption
• High Environmental Performance and Reliability
• Anti-Reflective Protective Glass
• Wide Operational Temperature Range, 0°C to +50°C (32°F to +122°F)
• RoHS Compliant
• VESA mount compliant.




Options:

• Optional Custom fitting for purging the monitor's enclosure
• Optional for 9-36V DC input
• Optional 5 Wired Resistive touch/ IR/ PCap Touch Screen (USB Default/ RS232 per request controller)
• Optional High Brightness 1000nits For Semi outdoor application
• Optional for Auto Dimming Sensor
• Optional for IR Remote Control with Front Sensor.
• Optional Heater for lower temperatures -30C (-22F)
• Optional Integrated VGA/ DVI Extender
-Transmission length up to 1,000ft over CAT5e cable for VGA input
- Transmission length up to 300ft over CAT5e cable for DVI input





Rugged Completely Sealed IP66/NEMA4X Stainless Steel Chassis/Surface Mount LCD Monitor


Features Highlights:

  • 1.Water Proof Solution, Full IP/NEMA4 Rating
    front and back, Stainless and Aluminum Housing Chassis Design
  • 2. AR Glass Protective Glass at front.
  • 3. Optional High Brightness and Touch screen.

  • IP65 Water and Dust proof connection for a higher protection
  • All Connectors are facing backward

  • Optional DC 9-36V input


Specifications:

LCD Display
Size / Panel Type 17” SXGA Color TFT LCD Panel
Resolution 1280 x 1024
Brightness (cd/m²) 1000cd/m²
Contrast Ratio 1000 : 1
Response Time 5 ms
Backlight LED Backlight Unit
Colors 16.2M colors
Viewing Angles 140º / 130º
Surface Hardness 7~8H, AR Glass
Touch Screen (Optional)
Touch Screen Type Resistive Touch / PCT Touch (Optional)
Surface Hardness 3H / 7H
Environment
Operating Temperature 0°C~+50ºC
Storage Temperature -20°C~+60°C
Humidity 5%~95% RH(Non-Condensing)
Water-Proof Rating IP66/NEMA4, 6 Side Water-Proof
System
CPU / Memory Intel Atom D2550 Dual Core 1.86Ghz / 4GB DDR3
OSD Menu, Auto, On/Off, Up, Down
I/O Interface DVI x 1 + RS232 x 1 + USB x 2 + POWER x 1 + LAN x 1
Power Input 12 VDC ( Optional : 9~36VDC)
Power Consumption 33W
Certification FCC/CE/RoHS Compliance
Mounting VESA 75 x 75mm;100 x 100mm
Dimension/Weight 429mm (W) x 361.5mm (H) x 50mm (D) / 10.5kgs


Accessories

Water proof DVI cable 6ft long x 1
Water proof LAN cable 6ft long x 1
Water proof Power cable 6ft long x 1
RS232 Connector 6ft long x 1
USB Connector 6ft long x 2
