21.5" Industrial All-In-One System with Intel® ATOM D2550 processor, 2xLAN, 6x COM, 1xLPT NM10 System (Model: RAO2100-AT)

21.5" Industrial All-In-One System with Intel® ATOM D2550 processor, 2xLAN, 6x COM, 1xLPT NM10 System (Model: RAO2100-AT)

21.5" Industrial All-In-One System with Intel® ATOM D2550 processor, 2xLAN, 6x COM, 1xLPT NM10 System (Model: RAO2100-AT)

RAO2100-AT
  • Overview
  • Download

Features :

  • 21.5” TFT SXGA (1920x1080) LCD
  • Intel® ATOM D2550 Processor
  • 2x RJ-45 Gigabit LAN, Wake-on-LAN, PXE ready
  • 6x COM : 5x RS232(COM1/3/4/5/6), 1x RS485/422/232 (COM2)
    (COM1~6, support 5v/12v)
  • 1x Parallel port
  • GPIO (4x In, 4x Out)
  • Mini PCI-E x1 expansion
  • 1x SIM socket
  • 5 wire Resistive Touchscreen (Optional).
  • Card reader support MS HG



Specifications:

Processor Intel ATOM D2550 1.86G dual-core processor
Chipset Intel® NM10 Express chipset
Memory 2 x DDR3 800/1066 SO-DIMM up to 8GB dual channel.
Storage 3.5" SATA hard drive

Tray-in Slim DVD Multi
Video 21.5" (1920 x 1080) TFT-LCD with LED backlight, 16.7M colors

Intel GMA3650 graphic core (share memory up to 512MB)
Supports Hardware H.264/AVC, MPEG-2 video decoder, VC-1, DirectX 9, 1080p decoder

VGA DB-15 / DVI port (support ~ 1920x1200 resolution)

Support for simultaneous display on LCD and external monitor
Audio Realtek ALC888 HD 6-channel CODEC

Two integrated stereo speakers

Line out / line in / microphone ports
Interface ports Rear side :
2x RJ45 LAN
4x USB 2.0
4x Serial : 3x RS232(COM1/3/4), 1x RS485/422/232(COM2)
1x Parallel port
VGA
DVI
DC-in

Left side :
SD/MS HG/MMC
4x USB 2.0 (1x on card reader)
Line out / line in / microphone
USB Port External : 8x USB 2.0 ports.
Internal : 2x USB 2.0 ports.
Webcam 1.3M pixels, 1280 x 1024 resolution
Card Reader SD/MS HG/MMC
Expansion Slots 1x Mini PCI-E slot
1x SIM socket
Communications 2x Intel 82574L Gigabit LAN, Wake-on-LAN, PXE ready
GPIO interface Onboard Programmable 8-bit Digital I/O interface(4 In+4 Out)
Internal IO port 1x PS2 KB/Mouse ; 4x RS232 ; 1x SMBus ; 1x SPDIF/out
Watch Dog Can be set by 500ms, 1, 2, 4 seconds period. RESET or NMI was generated when CPU did not periodically trigger the timer
Power Lost Recovery BIOS support AT mode boot up
Dimensions 21.2" (538.3mm) W x 17.8" (452.3mm) H x 3.3" (84.5mm) D, without stand
Net Weight 22.9 lb. (10.4kg)
Power Adapter Input : AC / 100~240V (50/60Hz) 1.8A Output : DC/12V, 5A 60W, 4 pin
OPTIONAL
Color Black/White
Wireless LAN 802.11 b/g/n or a/b/g
Bluetooth module Bluetooth v4.0 + EDR
Touch Screen 21.5", 5 wire resistive touch screen
OS Windows 7 Pro OEM / Embedded
