21.5" Wide LCD Rugged Completely Sealed IP65 / NEMA4X Stainless Steel Chassis Mount, Water / Dust proof (Model: WCH2150A3-IP)

21.5" Wide LCD Rugged Completely Sealed IP65 / NEMA4X Stainless Steel Chassis Mount, Water / Dust proof (Model: WCH2150A3-IP)

21.5" Wide LCD Rugged Completely Sealed IP65 / NEMA4X Stainless Steel Chassis Mount, Water / Dust proof (Model: WCH2150A3-IP)

WCH2150A3-IP
  • Overview
  • Download

Features

  • Enclosure: Completely sealed, IP65 (NEMA4) grade.
  • Widely used in chemical industry, food industry, medical devices, appliances etc. with good corrosion resistance.
  • Stainless Material:
    CNS JIS ASTM AISI DIM
    304 SUS 304 S30400 304 1.4301


Specification

Technical Description
Screen Size (diagonal) 21.5"(16:9)
Active Display Area (mm) 476.64 (H) x 268.11 (V)
Pixel Pitch (mm) 248.25(per one triad)(H) x 248.25(V)
Native Display Resolution (pixels) 1920x1080
Brightness (CD/m^2) 250 (typ.)
Contrast Ratio 1000:1 (typ.)
Viewing Angles (L/R/U/D) -85~85 (H); -80~80 (V)
Number of Colors 16.7M (8bits/color)
Optional Touch Screen Resistive
Power Information
Power Source DC12V in (with IP65 connecter)
Power Consumption(Normal operation) 50 W typical, normal operation
Power Input VESA DPMS Compliant
Display Signals
VGA Input Yes
Plug & Play VESA DDC 1/2B
Video Input (optional) Optional
DVI Input (optional) No
RS232 Remote Control (Optional) Optional

*Due to Panel material's deviation, different panel supplier will set different specific variance range to optical characteristics. The factors of time used, Lamp current, Ambient temperature will influence the optical measurements.
