Fanless Panel PC 17" Core2Duo 2.0GHz GM45 2GB (Max8GB) 2.5" 320GB 2 GigaLAN 4 COM3 @ 422/485 120W Adapter XP Pro 350 cd/m2 PCI x1 (Model: BBC1700CD)
- Overview
- Download
Fanless Panel PC 17" Core2Duo 2.0GHz GM45 2GB (Max8GB) 2.5" 320GB 2 GigaLAN 4 COM3 @ 422/485 120W Adapter XP Pro 350 cd/m2 PCI x1 (Model: BBC1700CD)
X
Inquiry/Quote Request
Features
• Intel socket P, support Intel T3100 1.9GHz and up to Intel P8600 2.4GHz processor• Front Panel IP65
• Supports 1 x PCI Expansion Slot
• Resistive Touch Screen for Option
• Wide Range 9-32V DC Input
Specifications
| System | |
| CPU | Intel socket P, support Intel T3100 1.9GHz and up to Intel P8600 2.4GHz processor |
| DRAM | 2 x 204 Pin SO-DIMM, up to 8GB DDR3 800/1066MHZ FSB |
| Storage | 1 x CF slot internal (option) |
| Rear Side I/O Port | • 4 x USB 2.0 • 2 x GbE LAN • 1 x Audio jack line out and MIC in • 1 xVGA • 2 x RS-232 (COM1 and COM2) • 1 x DB-9 RS-422/48S default:RS-485 (COM3) • 1 x Terminal block for additional power switch • 2 x LED light for power and HDD indication • 1 x Rocker Switch for Power ON/OFF • 2 x USB 2.0 for option |
| CD/DVD-R Device | None |
| Touch Screen | Analog resistive (optional) |
| Expansion | 1 x PCI slot |
| Power supply | 9-32V DC |
| Display | |
| LCD | 17" Color TFT |
| Luminance (cd/m2) | 350 |
| Max. Color | 16.7M |
| Resolution | 1280x1024 |
| View Angle | 170/160 |
| Backlight Lifetime | 50,000 hrs |
| Mechanical | |
| Construction | Steel Housing |
| Dimensions (WxHxD) | 439x348x93.3 |
| IP Rating | Front Panel IP65 Compliance |
| Mounting | Panel and VESA 75 Mount |
| Environmental | |
| Operating Temperature | -10~50°C |
| Storage Temperature | -20~60°C |
| Storage Humidity | 10~90% @40°C, non-condensing |
| Certificate | CE/FCC Class A Compliance |
